Quick-Start Guide

To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.

Manual Revision: August 2, 2022 8:40 AM

Product ID

HDMI-SPLITTER-4K60UP

Top View

Front View Rear View

ComponentFunction

1HDMI Input Dongle Cable• Connect to an HDMI Source Device

2Reset Button

• Resets the , forcing re-detection of HDMI Splitter

the HDMI Displays

3HDMI Output 2• Connect to an HDMI Display

4Display Activity LEDs

• Solid Blue: HDMI DisplayConnection to an

detected

5HDMI Output 1• Connect to an HDMI Display

6USB Micro-B Power Port

• Connect to the included for USB Wall Charger

power

7Power LED• Solid Blue: Indicates if power is being received

2-Port Portable HDMI® Video Splitter with USB Power - 4K 60Hz

Product Information

For the latest manuals, product information, technical specications, and declarations of

conformance, please visit: www.StarTech.com/HDMI-SPLITTER-4K60UP

Package Contents

• 2-Port HDMI Splitter x 1

• USB Micro-B Cable x 1

• USB Wall Charger x 1

• Quick-Start Guide x 1

Requirements

• HDMI Source x 1

• HDMI Display x 2

• HDMI Cables (sold separately) x 2

Installation

Note: Ensure your HDMI Source Device, and the HDMI Displays are powered o before

you begin installation.

1. Connect the on the to the HDMI Input Dongle CableHDMI SplitterHDMI Output

Port HDMI Source Deviceof your .

2. Connect the (not included) from each of the on HDMI cables HDMI Output Ports

the to the on your .HDMI Splitter,HDMI Input PortHDMI Displays

Note: Each port is numbered, please take note of which number is assigned to each

HDMI-enabled display device.

3. Power on each , followed by your .HDMI DisplayHDMI Source Device

4. Plug in the included to an available . USB Wall ChargerWall Outlet

5. Connect the included from the , to the USB Micro-B CableUSB Wall ChargerUSB

Micro-B Power PortHDMI Splitter, located on the rear of the .

6. Your will now display an identical image on each attached HDMI Source Device

HDMI-enabled display device.

1

35

6

7

4

2
