Quick-Start Guide

To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.

Manual Revision: June 9, 2020

Product Diagram (IESC1G50UP)

Front View

Side View

ComponentFunction

1PoE Ports

• Connect any to provide an Network DeviceEthernet

ConnectionNetwork Devices to up to 4

• Provide a to 4 PoE ConnectionDevices

• Maximum PoE power budget is 30W per port up to a

total overall power budget of 120W

5 Port Unmanaged Industrial-Grade PoE Switch 10/100/1000 Mbps

2PW2 LED Indicator

• Color - Green

• On - when and are connectedV2+V2-

• O- when and are not connected V2+V2-

3PW1 LED Indicator

• Color - Green

• On - when and are connectedV1+V1-

• O- when and are not connectedV1+V1-

4Non-PoE Port

• Connect any to provide an Network DeviceEthernet

ConnectionNetwork Device to one

5PoE LED Indicators

• Indicates the link and status PoEPowered Device (PD)

of each PoE Port

LNK(Green)

• On - Network connection detected

• O - Network connection not detected

• Flashing - Networkis active

PoE (Amber)

• On - is detectedPoE PD

• O - is not detectedPoE PD

6

Terminal Block Power

Input Port

• Provides power to the PoE Ports

• Supported power input voltage range is 48-56V

7Grounding Point

• Attach a to protect Grounding WireNetwork

Equipment

Requirements

For the latest requirements, please visit .www.startech.com/IESC1G50UP

• DC Power Supply x 1 (maximum of 2)

• PoE Powered Device x (up to) 5

• RJ45 Terminated UTP/STP Cat 5e (or better) Network Cable (sold separately) x 5

• Earth Ground Connection x 1

• Grounding Wire x 1

• (Optional - for power) Flat Head Screwdriver x 1

• (Optional) #2 Phillips Head Screwdriver x 1

• (Optional) Screws for Wall Mounting x 2

67

2

3

1

5

4
