Quick-Start Guide

To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.

Manual Revision: June 2, 2020 2:08 PM

Product Diagram (IMC100MSFP)

ComponentFunction

1PWR LED

• An external is Green:DC Power Source

detected.

• An external is not O:DC Power Source

detected.

2LK/Act LED

• Indicates that a link is detected on the Green:

SFP.

• Indicates that data is being Flashing:

transmitted or received.

3RJ45 Port

• Connect a to the Network DeviceMedia

Converter.

Green:

• A network connection is detected.On:

• The is Flashing:Media Converter

transmitting/receiving data.

Amber:

• 100Mbps network speed detected.On:

• 10Mbps network speed detected.O:

Industrial RJ45 to Open SFP Media Converter | Fast Ethernet 10/100 Mbps

4DIP Switch

DIP 1:

• Enables converter mode.Up:

• Enables switch mode (default).Down:

DIP 2:

• Enables Link Fault Pass-Through (LFP) Up:

function, LFP highlights link failures, by forcing

a link down between both connections during

a link failure.

• Disables LFP function (default).Down:

5SFP Slots

• Connect an (100BASE-X) to the SFPMedia

Converter.

63-Pin Terminal Block

• Connect an external (12-56V DC Power Source

DC Input) to the .Media Converter

Requirements

For the latest requirements, please visit www.startech.com/IMC100MSFP

• Network Equipment (ex. Router, Network Switch) x 1

• MSA-Compliant 100BASE-X SFP Transceiver Module x 1

• RJ45 Terminated UTP/STP CAT5e (or better) Network Cable x 1

• Terminated Fiber Optic Cable (dependent on SFP Module) x 1

• DC Power Source x 1

• Phillips Head Screwdriver x 1

• Small Flat Head Screwdriver x 1

Powering the Media Converter

Connecting and installing the must be completed by a 3-Wire Terminal Connector

licensed Electrician.

Notes: Make sure that you turn o the power source before connecting the power wire

to the .Media Converter

Do not exceed the recommend power source voltage as it may result in personal or

product damage.

1. Using a , loosen the V- and V+ screws on the Small Flat Head Screwdriver3-Wire

Terminal Connector (included).

1

6

2

35

4
