Quick-Start Guide

To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.

Manual Revision: July 10, 2020

Product Diagram (MONSTADQI)

ComponentFunction

1

Stand Top with

Integrated Qi Charger

• 23.6 x 9.8 inches (600 x 250 mm) surface area

• Holds a , a MonitorMobile Device with

Wireless Charging Capabilities, and a

Notebook/Paper Documents

2Legs

• Adjustable height:

• Legs folded down - 3.3 inches (83.5 mm)

• Legs folded up - 4.5 inches (115.5 mm)

3Qi Charger

• 15W Charging for a Mobile Device with

Wireless Charging Capabilities

4Power Cable

• Connect the (included) to Power Adapter

provide power to the Qi Charger

Requirements

For the latest requirements and full manual, please visit:

www.startech.com/MONSTADQI.

• Mobile Device with Wireless Charging Capabilities x 1

• Clean, Flat, and Stable Surface

Installation

Assembling the Monitor Riser

1. Determine the desired height for the .Stand Top

Monitor Riser with Integrated Qi Charging Pad

2. (Optional -- Increase the height of the ) Rotate the Monitor Riser LegsHeight

Adjustment Arms LegsHeight found on the sides of the out and up. The

Adjustment Arms LegsHeight pivot from a single point in the . Ensure all four

Adjustment Arms have been fully rotated out and up before proceeding to the next

step. (Figure 1)

3. Place the , top side down, onto a .Stand TopClean, Flat, and Stable Surface

4. Align the two on one of the with the two in the PegsLegsHolesStand Top.

(Figure 2)

5. Firmly press the two on one of the into the two in the PegsLegsHolesStand Top.

6. Repeat steps 4-5 to install the second .Leg

7. Flip the upright and position it on a Monitor Riser AssemblyClean, Flat, and

Stable Surface for use.

8. Connect the to the and to an available . Power AdapterPower Cable Power Source

1

2

4

3

Figure 1

Figure 2

Pegs
