Quick-Start Guide

To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.

Manual Revision: March 10, 2021

Product Diagram (PCI2S1P2)

Front View

PortFunction

1Parallel Connector • Connect to the on the Parallel PinsPCI Card

2

Low-Prole Bracket

(Parallel)

• SeeInstalling the Low-Prole Bracket(s)

3Parallel Port

• Connect a Parallel Peripheral Device

• DB-25 Parallel (Female)

4

Low-Prole Brackets

(Serial)

• SeeInstalling the Low-Prole Bracket(s)

5Serial Ports

• Connect Serial Peripheral Devices

• DB-9 Parallel (Male)

6 PCI Connector

• Connect the to the in the PCI Card PCI Slot

Computer

Package Contents

• PCI Serial Parallel Combo Card x 1

• Full-Prole Bracket (Installed) x 1

• Low-Prole Brackets (for Serial Ports) x 2

• Low-Prole Bracket (for Parallel Port) x 1

• Quick-Start Guide x 1

2S1P PCI Serial Parallel Combo Card with 16C550 UART

Requirements

For the latest requirements, please visit:

www.startech.com/PCI2S1P2.

• Computer with an available PCI slot (x4/8/16)

• Needle-nose Pliers or 3/16 Nut Driver

Hardware Installation

Warning: PCI Cards can be damaged by static electricity. Make sure that the

InstallerComputer Case is properly grounded before they open the or touch the PCI

Card. The should wear an when installing any computer InstallerAnti-Static Strap

component. If an is not available, discharge any built-up static Anti-Static Strap

electricity by touching a large for several seconds. Only Grounded Metal Surface

handle theby its edges and do not touch the gold connectors. PCI Card

Installing the Low-Prole Bracket(s)

By default the is attached to the . Full-Prole BracketSerial/Parallel Port(s)

Depending on the system conguration it may be necessary to remove the Full-

Prole Bracket(s)Low-Prole Bracket(s) to replace with the (included).

1. Remove the from both sides of each , using a Hexagonal StandosPort3/16 Nut

Driver Needle-nose Pliersor a pair of .

2. Remove the and replace with the .Full-Prole Bracket(s) Low-Prole Bracket(s)

3. Install the removed in step 1. Thread the Hexagonal Standos Hexagonal

StandosThreaded Post3/16 Nut Driver onto each and tighten, using a or a pair

of .Needle-nose Pliers

Installing the Card

1. Turn o the and any that are connected ComputerPeripheral Devices

(e.g. printers, external hard drives, etc.).

2. Unplug the from the rear of the and disconnect any Power CableComputer

Peripheral Devices that are connected.

3. Remove the from the . CoverComputer Case

Note: Consult the documentation that came with the for details about Computer

how to do this safely.

4. Locate an open and remove the corresponding from the PCI SlotMetal Cover Plate

rear of the . In most instances, the is attached Computer CaseMetal Cover Plate

to the rear of the with a single . Save this for the next Computer CaseScrewScrew

step.

6

3

2

5

4

1
