Quick-Start Guide
To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.
Product Diagram (PRESREMOTEG)
Button/LEDFunction
1LED Indicator
Indicates remote activity, lights up when buttons on the
Remote are pressed.
Notes: The USB Wireless Receiver must be removed
from the remote for the LED Indicator to work.
The LED Indicator will ash when the batteries need to
be replaced.
2Play/ESC
Starts or ends the presentation within compatible
software.
Used as the Back button when in menus.
Used as the zoom out function when zoomed in.
3Last
Moves to the previous action. (animations, transitions,
slides, etc.).
Wireless Presentation Remote with Green Laser Pointer
1
Button/LEDFunction
4Tab
Cycles through on-screen elements.
Note: When not presenting, the Tab Button cycles
through screen elements on the screen the mouse
indicator is located.
5Laser
Activates the Laser Pointer.
Note: The USB Wireless Receiver must be removed
from the remote for the Laser Pointer to work.
6
USB Wireless
Receiver
Connects the Remote to the Host Computer.
7Volume UpTurns the Host Computer’s volume up.
8Volume DownTurns the Host Computer’s volume down
9BlankTurns the screen O/On.
10Next
Moves to the Next action (animations, transitions,
slides, etc.).
11EnterEmulates the Enter/Return button on a keyboard.
Requirements
For the latest requirements, please visit www.startech.com/PRESREMOTEG.
• Host Computer with USB-A Port.
Battery Installation
1. Press down on the Battery Bay and slide the Battery Cover away to reveal the
Battery Compartment.
2. Insert two AAA Batteries (included), aligning the positive (+) and negative (-) ends
of the batteries with the indicators inside the Battery Compartment.
3. Align the Battery Cover on the back of the Remote and slide it back into place.
Connecting the Remote
1. Remove the USB Wireless Receiver from the Storage Slot on the bottom of the
Remote.
2. Connect the USB Wireless Receiver to a USB-A Port on the Host Computer.
Note: The Remote will appear as 2.4G PRESENTER in system menus on the Host
Computer.
ATTENTION!
DO NOT STARE INTO BEAM
DO NOT POINT AT AIRCRAFT
Class 2 Laser Product
LASER RADIATION
WAVELENGTH: 532 ± 10nm
Max optical power: 1mW
2
3
46
10
9
7
8
5
11
Produktspezifikationen
| Marke: | StarTech.com |
| Kategorie: | Kabelloser Presenter |
| Modell: | PRESREMOTE |
| Breite: | 31 mm |
| Tiefe: | 134 mm |
| Gewicht: | 120 g |
| Produktfarbe: | Schwarz |
| Akku-/Batterietyp: | AAA |
| Akku-/Batterietechnologie: | Alkali |
| Höhe: | 25 mm |
| Betriebstemperatur: | 5 - 45 °C |
| Verpackungsbreite: | 98 mm |
| Verpackungstiefe: | 195 mm |
| Verpackungshöhe: | 44 mm |
| Paketgewicht: | 180 g |
| Schnellstartübersicht: | Ja |
| Zertifizierung: | CE, FCC |
| Kabellose Reichweite: | 27 m |
| Kabelloser Receiver-Anschluss: | USB |
| Anzahl unterstützter Akkus/Batterien: | 2 |
| Frequenzband: | 2.4 GHz |
| Tragetasche: | Ja |
| Formfaktor: | Dongle |
| Receiver enthalten: | Ja |
| Akkus/Batterien enthalten: | Ja |
| Nachhaltigkeitszertifikate: | RoHS |
| Laserklasse: | 2 |
| Wellenlängenbereich: | 650 - 670 nm |
| Laserwellenkraft: | 1 mW |
