StarTech.com RACKCONS17HD Bedienungsanleitung

StarTech.com Schalter RACKCONS17HD

Lies die bedienungsanleitung für StarTech.com RACKCONS17HD (20 Seiten) kostenlos online; sie gehört zur Kategorie Schalter. Dieses Handbuch wurde von 4 Personen als hilfreich bewertet und erhielt im Schnitt 4.8 Sterne aus 2.5 Bewertungen. Hast du eine Frage zu StarTech.com RACKCONS17HD oder möchtest du andere Nutzer dieses Produkts befragen? Stelle eine Frage

Download PDF

Seite 1/20

Manual Revision: 05/09/2019

For the most up-to-date information, please visit: www.startech.com

DE: Bedienungsanleitung - de.startech.com

FR: Guide de l'utilisateur - fr.startech.com

ES: Guía del usuario - es.startech.com

IT: Guida per l'uso - it.startech.com

NL: Gebruiksaanwijzing - nl.startech.com

PT: Guia do usuário - pt.startech.com

RACKCONS17HD / RKCONS17HDGB

1U 17in 1080p LCD Rack Console with Front

USB Hub

*actual product may vary from photos

Instruction Manual

FCC Compliance Statement

This equipment has been tested and found to comply with the limits for a Class B digital

device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable

protection against harmful interference in a residential installation. This equipment generates,

uses and can radiate radio frequency energy and, if not installed and used in accordance with

the instructions, may cause harmful interference to radio communications. However, there

is no guarantee that interference will not occur in a particular installation. If this equipment

does cause harmful interference to radio or television reception, which can be determined by

turning the equipment o and on, the user is encouraged to try to correct the interference by

one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit dierent from that to which the receiver

is connected.

• Consult the dealer or an experienced radio/TV technician for help.

Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols

This manual may make reference to trademarks, registered trademarks, and other

protected names and/or symbols of third-party companies not related in any way to

StarTech.com. Where they occur these references are for illustrative purposes only and do not

represent an endorsement of a product or service by StarTech.com, or an endorsement of the

product(s) to which this manual applies by the third-party company in question. Regardless

of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby

acknowledges that all trademarks, registered trademarks, service marks, and other protected

names and/or symbols contained in this manual and related documents are the property of

their respective holders.

Instruction Manual

Table of Contents

Product Overview ..................................................................................1

Front View .................................................................................................................................................... 1

Rear View ......................................................................................................................................................1

Introduction ............................................................................................2

Packaging Contents 2 .................................................................................................................................

Front Panel Controls 3 .................................................................................................................................

Installation .............................................................................................3

Rail Installation A 4 .......................................................................................................................................

Rail Installation B 5 .......................................................................................................................................

Rail Installation C 8 .......................................................................................................................................

Console Installation ...............................................................................12

PC / Server Connection 13 ...........................................................................................................................

Connecting to a KVM Switch 14 ................................................................................................................

Operation 14 ................................................................................................

Specications 15 ..........................................................................................

Technical Support ..................................................................................16

Warranty Information ............................................................................16

Produktspezifikationen

Marke:	StarTech.com
Kategorie:	Schalter
Modell:	RACKCONS17HD
Bildschirmdiagonale:	17 "
Anzahl der Farben des Displays:	16,78 Millionen Farben
Breite:	448 mm
Tiefe:	460 mm
Gewicht:	13000 g
Mitgelieferte Kabel:	KVM, USB
Höhe:	44 mm
Betriebstemperatur:	0 - 50 °C
Paketgewicht:	20500 g
Display:	TFT-LCD
Stromverbrauch (Standardbetrieb):	23.35 W
Netzteil Eingansgsspannung:	100 - 240 V
Helligkeit:	300 cd/m²
Kontrastverhältnis:	650:1
Bildwinkel, horizontal:	140 °
Bildwinkel, vertikal:	120 °
Temperaturbereich bei Lagerung:	-20 - 60 °C
Schnittstelle:	DVI-I, VGA, 2xPS/2, 2xUSB
Größe (Imperial):	17 "
Mittlere Betriebsdauer zwischen Ausfällen (MTBF):	50000 h
Seitenverhältnis:	16:9
Pixel Abstand:	0.264 x 0.264 mm
Integriertes Touchpad:	Ja
Rack-Kapazität:	1U
Eingebaute KVM-Umschaltung:	Ja
