Quick start guide

DE: Bedienungsanleitung - de.startech.com

FR: Guide de l'utilisateur - fr.startech.com

ES: Guía del usuario - es.startech.com

IT: Guida per l'uso - it.startech.com

NL: Gebruiksaanwijzing - nl.startech.com

PT: Guia do usuário - pt.startech.com

Manual Revision: 04/29/2015

For the latest information, technical specications, and support for

this product, please visit www.startech.com/ST4000SPEXI.

Packaging contents

• 1 x 4-port PCI Express® network card

• 1 x low-prole bracket

• 1 x instruction manual

System requirements

• Computer with an available PCI Express slot (x4, x8, or x16)

• Any of the following operating systems:

• Windows® 7 (32-bit or 64-bit)

• Windows 8 (32-bit or 64-bit)

• Windows 8.1 (32-bit or 64-bit)

• Windows Server® 2003

• Windows Server 2008 R2

• Windows Server 2012

• Linux® Kernel 2.6.x and later

• Linux Kernel 3.x and later

• Microsoft® Hyper-V®

Note: Operating system requirements are subject to change. For the

latest requirements, please visit www.startech.com/ST4000SPEXI.

ST4000SPEXI

4-port PCI Express Gigabit Ethernet network card - Intel chip

*actual product may vary from photos

Installation

Install the PCI Express card

WARNING!

PCI Express cards can be severely damaged by static electricity. Make

sure that you’re properly grounded before you open your computer

case or touch your PCI Express card. StarTech.com recommends

that you wear an anti-static strap when you install any computer

component. If an anti-static strap isn’t available, discharge any built-

up static electricity by touching a large grounded metal surface (for

example, a computer case) for several seconds. Only handle the PCI

Express card by its edges and don’t touch the gold connectors.

1. Turn o your computer and any devices or peripherals connected

to it (for example, printers, external hard drives, and so on).

2. Unplug the power cable from the back of your computer.

3. Disconnect any peripheral devices that are connected to your

computer.

4. Remove the cover from your computer case. Consult the

documentation that came with your computer for details about

how to do this safely.

5. Locate an open PCI Express slot and remove the corresponding

metal cover plate from the back of the computer case. Consult

the documentation that came with your computer for details

about how to do this safely.

6. Gently insert the card into the open PCI Express slot and fasten

the bracket to the back of the case.

Note: If you install the card into a small form factor or a low-prole

desktop system, it may be necessary to replace the preinstalled

standard-prole bracket with the included low-prole (half-height)

installation bracket.

7. Place the cover back onto your computer case.

8. Reconnect the power cable to the back of your computer.

9. Reconnect all of the peripheral devices that you disconnected in

step 3.

10. Turn on your computer.

Install drivers on a computer running Windows

1. If the Found New Hardware dialog box appears on your screen,

close the dialog box or click Cancel.

2. To download the latest drivers, navigate to www.StarTech.com

and enter ST4000SPEXI in the Search eld.

3. Click the Support tab.

4. Download a driver.

5. When the download is complete, extract the contents of the

compressed le that you downloaded.

6. Double-click the appropriate driver for the version of Windows

that you’re running and follow the on-screen instructions to

complete the installation.

Product diagram

Ethernet ports

Link or activity

LED
