Seite 1/16

The Professionalsí Source For Hard-to-Find Computer Parts

KVM SWITCH

SV831HD

SV1631HD

SV1631D1U

Instruction Guide

* SV831HD shown

* Actual product may vary from photo

Table of Contents

Introduction ................................................................................................2

System Requirements................................................................................2

Installation ..................................................................................................3

Operating Your KVM Switch.......................................................................4

Pushbuttons ...............................................................................................4

OSD Operations.........................................................................................4

OSD Function Keys....................................................................................5

Hot Key Commands ...................................................................................8

Changing Your Configuration .....................................................................9

Keyboard Mapping ...................................................................................10

Troubleshooting .......................................................................................11

Technical Specifications...........................................................................12

Technical Support ....................................................................................13

Warranty Information................................................................................13

Introduction

Thank you for purchasing a StarTech.com 1U KVM switch. Our universal KVM switches let you control

either 8 (SV831HD) or 16 (SV1631HD) USB or PS/2 computers using only one PS/2 keyboard, mouse,

and monitor. Our slim 16-port PS/2 switch (SV1631D1U) lets you connect 16 PS/2 computers using only

one PS/2 keyboard, mouse, and monitor. Switching between your PCs is easy thanks to pushbutton or hot-

key commands. These slim KVM switches take up only 1U of space in your cabinet and use rear cable

connections for maximum space efficiency. Each KVM can be cascaded to support 64 (SV831HD) or 136

(SV1631HD, SV1631D1U) computers and support both Manual and Auto scan modes for easy monitoring

of your PCs.

Features

• SV831HD, SV1631HD: Supports PCs with both USB and PS/2 keyboard/mouse connections

• SV1631D1U: Supports PCs with PS/2 keyboard/mouse connections

• Saves valuable rack space with thin 1U height form factor

• Supports hot-plugging: allows computers to be added or removed without having to reboot the

other connected systems

• SV831HD, SV1631HD: Works with PC, Mac, and Sun systems

• Fast switch-buttons for each port provide quick access to any connected system

• Uses On-Screen Display (OSD) menu for easy PC selection and switch configuration

• Can be cascaded to control up to 64 (SV831HD) or 136 (SV1631HD, SV1631D1U) PCs

• Visible front panel LEDs show status for each connected device

• Allows effortless monitoring of devices through configurable Auto and Manual scan modes

• Acts independent of operating system: no software or drivers required

• Complies with Plug and Play specifications

• Backed by StarTech.com’s 3-year warranty

Before You Begin

To ensure a quick and easy console installation, please read through this section carefully before attempting

to install the device.

Contents

This package should contain:

• 1 x StarView KVM Switch (SV831HD, SV1631HD, SV1631D1U)

• 1 x power adapter (9V 600mA DC)

System Requirements

• 1 x PS/2 mouse (6-pin mini-DIN male connector)

• 1 x PS/2 keyboard (6-pin mini-DIN male connector)

• 1 x HD-15 monitor (Male connector)

• SV831HD, SV1631HD: StarTech.com’s 2-in-1 USB KVM cables or 3-in-1 PS/2 KVM cables

• SV1631D1U: StarTech.com’s 3-in-1 PS/2 KVM cables

Produktspezifikationen

Marke:	StarTech.com
Kategorie:	Schalter
Modell:	SV1631HD
Übertragungstechnik:	Kabelgebunden
Zertifizierung:	CE, FCC
Energiebedarf:	9V DC, 0.6A
Rack-Einbau:	Ja
Maximale Auflösung:	1920 x 1440 Pixel
Weitere Anschlüsse:	1 - 8 DIN\n2 - 6 DIN\n17 - HD DB15
Anzahl Anschlüsse:	16
Rack-Kapazität:	1U
Tastatur Porttyp:	USB, PS/2
Maus-Porttyp:	USB, PS/2
