REV N DATE: 06/27/2023

USER MANUALS\20-78347_REVEAL_USER MANUAL_NR(L)(H)RRSSV_REF_COMBO_OVER-UNDER_CASE

SCC P/N

20-78347

USER

MANUAL

REVEAL® FREE STANDING OVER-UNDER REFRIGERATED COMBO MERCHANDISERS

> CONVERTIBLE UPPER SECTION MAY BE EITHER AMBIENT OR REFRIGERATED

> REFRIGERATED LOWER SECTION

> SELF-CONTAINED OR REMOTE UNITS

> UPPER SECTION: REAR SLIDING DOORS

> OPTIONAL RISERS (IN LIEU OF SHELVING)

> LOWER SECTION: REAR SLIDING DOORS WITH

PERFORATED ACRYLIC PLENUMS OR SOLID BACK PANELS

> CAUTION! DO NOT PUSH OR PULL ON UPPER GLASS ENCLOSURE!

> ONLY USE HANDLES (AT EACH END OF CASE) TO PUSH OR PULL CASE INTO POSITION!

Models Are Shipped WITHOUT

Panels and Cladding Attached.

See Pages 10 & 11 For Component

Attachment Instructions.

Reveal

READ AND SAVE THESE INSTRUCTIONS

®

Reveal® Model NR3631RRSSV

Self-Service Solid Back Rear Panel

Optional Product Steps / Shown As

Shipped From Factory (Without

Components) / Front Slide-Out

Access To Condenser Package

Reveal® Model NR3631RRSSV /

Rear Sliding Doors and Acrylic

Perforated Plenums / Shown As

Shipped From Factory (Without

Components) / Rear Slide-Out

Access To Condenser Package

Reveal® Model

NR4838RRSSV

Rear Sliding Doors

and Acrylic Perforated

Plenums / Cladding

Shown Attached

Structural Concepts Corp. ∙ 888 E. Porter Rd ∙ Muskegon, MI 49441 Phone: 231.798.8888 Fax: 231.798.4960 ∙ www.structuralconcepts.com
