Tabletop Stand Installation
(Note, the Tabletop Stand is an optional accessory. To order, contact your Authorized
SunBriteTV Dealer or SunBriteTV customer service.)
Tools Needed: Phillips screwdriver
Notes:
a. Do not attach the Tabletop Stand if you plan to install the TV on a wall mount or ceiling mount.
b. The Tabletop Stand can be installed either before or after the detachable speaker module
is installed. For purpose of demonstration, we are installing the Tabletop Stand without the
speaker module.
For demonstration purposes, this manual is showing how to install the right-half of the
Tabletop Stand. Because you will be working from the back of the TV, the Tabletop Stand will
appear on the left.
1. Prepare a at work surface, free of any debris or items which may scratch the front surface of
the TV.
2. Lay the TV face-down on the work surface with the bottom of the unit closest to you
WARNING: Use at least two people when transporting the TV.
3. Position the TV so that the bottom edge overhangs the table by about two inches.
4. The TV is shipped with three Tabletop Stand Mounting Screws on the TV, two on the back of
the TV, and one on the bottom. Remove the screws to expose Tabletop Stand Mounting Holes
(Figure 1). WARNING: Always replace tabletop mounting screws. Failure to do so will allow
water to seep inside your TV. This can cause serious injury and damage your TV.
5. The Tabletop Stand has adjacent Mounting Holes, two on the back and one on the bottom
(Figure 2).
6. Remove the Tabletop Stand Mounting Screws.
7. Place the Tabletop Stand on the TV so that the Tabletop Stand Mounting Holes align with
the TV Mounting Holes, and screw in the Tabletop Stand Mounting Screws to attach the Table
Mount to the TV. Secure tightly (Figures 3 and 4). See gure 5, 6 and 7 for images of installed
Tabletop Stand.
Tabletop Stand
Mounting Holes
on TV
Figure 1
Figure 2
Bottom
Back
Tabletop Stand
Tabletop Stand
Mounting Holes
Figure 3
Figure 4
WARNING: To prevent personal injury and/or damage to the
TV or personal property, use at least two strong people to
install or move the TV.
Front and back view of installed Tabletop Stand
Figure 5 Figure 6 Figure 7
Installation Instructions
Model SB-TS46 Tabletop Stand
For 46- and 55-inch series models
