SundingBicycleComputer
SD-201C(25Functions)
FUNCTIONS
-AUTOWAKEUP
-SPDCURRENTSPEED
-ODOODOMETER
0.001-99999km/m
-DSTTRIPDISTANCE
-MXSMAXIMUMSPEED
-AVSAVERAGESPEED
-TMELAPSEDTIME
-CLKCLOCK
12H/24H
-TMP
TMP
TMP
TEMPERTERATURE
-10~70
-MIN
-MAX
-SCAN
-COMPARATOR
-CAL
099999Kcal
-FAT09999.9kg
-SETTINGSPEEDSCALEkm/h,m/h
-SETTINGTYRECIRCUMFERENCE0mm9999mm
-SETTINGTHELASTVALUEOFODOMETER/ODO
-SETTINGRIDER’SWEIGHT
-FREEZEFRAMEMEMORY
-MAINTENANCEALERT
-“
”LOWPOWERREMINDING
-BACKLIGHT
-AUTOON/OFF
-WIRELESSDIGITALCODE
BatteryInstallation
Removethebatterycoverfromthebottomofthecomputerbyusinga
flatbladescrewdriver,installanCR2032batterywiththepositive(+)
polefacingthebatterycoverandreplacethecover.ShouldtheLCD
showirregularfigures,takeoutthebatteryandre-installit.
SpeedometerSensor
Attachthespeedometersensorbrackettotheleftforkblade,usingthe
shimstoadjustthediameter,andusingthecableo
tieitwiththefork.Positionthesensorandmagne
thatthearcofthemagnetintersectsthealignmer
with1mmclearance.
MountingShoe
Attachthemountingshoewiththecable
tiestothehandlebar,adjustthemounting
shoeonthehandlebarwiththeshimsto
holditsposition.
SensorWiring
Routethesensorwireuptheforkblade,
usingcabletiestosecureitatthebottom
andcrowntoavoidithinderthemovement
ofthefrontwheel.
Computer
Attachthecomputertothemountingshoe
byslidingtheunituntilitsnapsfirmlyinto
itspostion.Toremoveit,pressthebuttonon
itintheoppositedirection.
Tocheckforproperspeedfunctionandsensoralignment,spinthe
frontwheelwithcomputerinspeedmode.Adjustthepositionof
sensorandmagnetwhenthereisnoorweakreaction.
WheelSizeInput
‘2060’appearsonthescreenwhenthebatteryhasbeeninstalled,
withonefigureflashing,choosethecorrectwheelcircumferencefrom
thetablebelow.PressRIGHTbuttontoadvancedigitsasneededand
LEFTbuttontoconfirmandadvance.(Thecircumferenceranges
0mm
9999mm),pressLEFTbuttontoenterKM/Mmode.
TIRESIZE
CIRC
TIRESIZE
CIRC
700cx38mm218026’’x2.25’’2115
700cx35mm216826’’x2.1’’2095
700cx32mm215526’’x2.0’’2074
700cx30mm214526’’x1.9’’/1.95’’2055
700cx28mm213626’’x1.75’’2035
700cx25mm212426’’x1.5’’1985
700cx23mm210526’’x1.25’’1953
700cx20mm207426’’x1.0’’1913
700cTubulari213024’’x1.9’’/1.95’’1916
650cx23mm199020’’x1-1/4’’1618
650cx20mm194516’’x2.0’’1253
27’’x1-1/4’’216116’’x1.95’’1257
27’’x1-1/8’’215516’’x1.5’’1206
26’’x2.3’’2135
Settingkm/h/m/h
PresstheRIGHTbuttontochoosekm/horm/h.
PresstheLEFTbuttontoenterRider’sWeightsetting..
SettingRider’sWeight
Thedefaultweightis65kg,presstheRIGHTbuttontoadjustthe
flashingweightnumberaccordingtorider’sweight,pressLEFT
buttontoconfirmandadvance.Weightranges:20~150kg.Pressthe
LEFTbuttontoenterintoMaintenanceAlertsetting.
SettingMaintenanceAlert
WhilethedefaultMaintenanceAlertdigit200km/m
isflashing,PresstheRIGHTbuttontochoose
200/400/600/800km/m.
PresstheLEFTbuttonto
confirmandenterintoClockmode.(Whenthe
ODO>theMaintenanceAlertdigityouset,the
willappearonthescreentoalerttherider,
presstheLEFTbuttontocancelit.)
CLKMode(12H/24H)
InCLOCKMode,presstheLEFTbuttonfor3
secondstoenter12/24Hselection.Re-pressthe
LEFTbuttonfor12/24exchanging.Pressthe
RIGHTbuttontoenterHoursettingmode,when
thefigureindicatingHOURstarttoflash,pressthe
LEFTbuttontoadjustit.
ContinuetopresstheRIGHTbuttontoenterMinutesettingmode,
whenthefigureindicatingMINUTEstarttoflash,presstheLEFT
buttontoadjustitandRIGHTbuttontoconfirm,re-pressRIGHT
buttonto
enterODOmode.
SettingtheLastvalueofOdometer
InODOmode,presstheLEFTbuttonfor2
secondstosettheODOvalue,itsinitial
valueis0000.0.whenonefigureflashing,
pressRIGHTbuttontoadjustitandLEFT
buttontoconfirmit,andstarttosetthe
nextfigure.(afterre-installthebattery,
latestvaluecanbeinputtedaccordingtothevalueexists
beforethebatteryisre-installed).
ResetofMileageParameter
InODOmode,PressandholdbothRIGHTandLEFTbutton
simultaneouslyfor3secondstoclearthecircumferencevalueand
cancel(km/m)&MaintenanceAlertsetting.Theuserneedtoreset
thetyrecircumference,(km/m)&MaintenanceAlert,theoriginal
ODOvalueandCLOCKwillremainunaffected.
Speedometer
Whenridingspeedisshownallthetimeonthescreen,itranges:0-
99.9km/h(m/h),anditisaccurateto+/-0.1km/h(m/h).
SpeedComparator
Duringriding,¡øand¨‹willdispalyonthescreen,¡øindicatesthe
currentspeedishigherthanaveragespeed.¨‹indicatesthecurrent
speedislowerthanaveragespeed.
Odometer
InODOmode,thetotaldistanceisindicated
onthescreen,itsmileageranges:0.001
99999km(m).Thedisplaywillbebackto0
whenvalueexceedsitsmaximumlimit,press
theRIGHTbuttontoenterDSTmode.
TripDistance(DST)
InDSTmode,thedistanceforonetripis
indicatedonthescreen.Thisdistanceisstartto
becalculatedwhenDSTbeclearedto0.It
ranges:0~9999km(m),whenexceedtherangelimit,itwillrestart
from0automatically.InDSTmode,pressLEFTbuttonfor5seconds
tocleartheDST,MXS,AVS,TMrecords.PresstheRIGHTbuttonto
enterintoMXSmode.
MaximumSpeed(MXS)
InMXSmode,maximumspeedisindicatedon
thebottomline.PresstheLEFTbuttonfor5
secondstocleartherecordsofMXS,DST,AVS
andTM.PresstheRIGHTbuttontoenterAVS
mode.
AverageSpeed
InAVSmode,theaveragespeedforone
tripisindicatedonthescreen.Pressthe
LEFTbuttonfor5secondstoclearthe
AVS,DST,MXS,TMrecords.Pressthe
RIGHTbuttontoenterIntoTMmode.
TripTime
InTMmode,thetriptimeforonetripis
indicatedonthescreen.TMranges:
0:00:00~9:59:59,restartfrom0:00:00when
itexceedtherangelimit.InTMmode,press
theLEFTbuttonfor5secondstocleartheTM,DST,MXS,AVS
records.PresstheRIGHTbuttontoenterinto TMPmode.
Temperature(TMP)
In TMPmode,thecurrentoutdoor
temperatureisindicatedonthescreen.
MinimumTemperature(MIN TMP)
MaximumTemperature(MAX TMP)
Thedefaultdisplayfor TMPis
--
buttonfor5secondstoclear TMPMINMAX,DST,MXS,AVS.
PresstheRIGHTbuttontoenterintoCAL
mode.
CAL(Calory)
InCALmode,thetotalheatenergytherider
consumediscalculatedfromthelast
restorationofthecomputerisindicatedonthe
screen.Itranges:0~99999Kcal.PresstheRIGHTbuttontoenterinto
FATmode.
FAT
InFATmode,thetotalFATtherider
consumediscalculatedfromthelast
restorationofthecomputerisindicatedonthescreen.Itranges:
0~9999.9kg.PresstheRIGHTbuttontoenterintoScanmode.
SCAN
InSCANmode,theDST,MXS,AVS,TMare
indicatedinturnevery4seconds.Pressthe
RIGHTbuttontoenterintoCLKmode.
MenuHideFunction
InanymodeexceptCLKmode,presstheRIGHTbuttonfor
5seconds,thecomputerisgoingtoMenuhidemode,it
hidesMIN TMP,MAX TMP,CAL&FAT,whichwillnot
beindicatedonthescreenbutstillrunningwithouteffect.
AlsoinanymodeexceptCLKmode,presstheRIGHT
buttonfor5secondsagain,thesefunctionsareresumed.
SleepMode
Ifnosignalhasbeeninputtedfor300seconds,computer
willenterintoSleepmode,CLKremains.Itwillturnbackto
theformermodewithallthedatacollectedwhenanysignal
isinputtedoranybuttonispressed.
FREEZEFRAMEMEMORY
Inanymode,presstheLEFTbuttontoenterintoFreeze
Framememorymode,flashingTMdatawillappearonthe
screen,presstheRIGHTbuttontoviewtherecordsofDST,TM,AVS
andMXS.PresstheLEFTbuttontoendit.
BackLight
Thebacklightfunctionisswitchedonoroffwhenyoupressany
buttonduringPM:18
00800.Itwillnotworkatanyothertime.
LowPowerReminding
Whenthebatteryislowpower,thesymbolwillbeshining,
Whichremindstheridertochangeintoanewbattery.
Malfunctionsandproblems
Accessories
Malfunctionsproblems
NospeedometerImpropermagnet/sensoralignment
Inaccuratevalueis
indicated
Improperinput,suchaswheel
circumference.
Slowdisplay
response
Temperatureexceedsoperating
limits(
~5)
Blackdisplay
Toolongtimeinsunlight,should
takebacktoshadeforaperiod.
WeakdisplayPoorbatteryordeadbattery
Displaysirregular
figures
Takebatteryoutandreinstallit
after10seconds.
Abnormalsound
whenshaking
computer
RollingBallswitchvoice/shaking
thecomputerinsleepmode,
computerautoon.
Produktspezifikationen
| Marke: | Sunding |
| Kategorie: | Fahrradcomputer |
| Modell: | SD-201C |
