Seite 1/79

SuperStorageSystem

6038R-E1CR16N

USER’S MANUAL

1.0a

iii

Preface

About This Manual

This manual is written for professional system integrators and PC technicians. It

provides information for the installation and use of the SuperStorageSystem 6038R-

E1CR16N. Installation and maintainance should be performed by experienced

technicians only.

The SuperStorageSystem 6038R-E1CR16N is a high-end server based on the

SC836BE1C-R920B 3U chassis and the X10DRi-T4+ dual processor serverboard.

Manual Organization

Chapter 1: Introduction

The rst chapter provides a checklist of the main components included with the

server system and describes the main features of the X10DRi-T4+ serverboard and

the SC836BE1C-R920B chassis.

Chapter 2: Server Installation

This chapter describes the steps necessary to install the SuperStorageSystem

6038R-E1CR16N into a rack and check out the server conguration prior to pow-

ering up the system. If your server was ordered without processor and memory

components, this chapter will refer you to the appropriate sections of the manual

for their installation.

Chapter 3: System Interface

Refer here for details on the system interface, which includes the functions and

information provided by the control panel on the chassis as well as other LEDs

located throughout the system.

Chapter 4: Safety Warnings

You should thoroughly familiarize yourself with this chapter for a general overview

of safety precautions that should be followed when installing and servicing the

SuperStorageSystem 6038R-E1CR16N.

The information in this User’s Manual has been carefully reviewed and is believed to be accurate.

The vendor assumes no responsibility for any inaccuracies that may be contained in this document,

makes no commitment to update or to keep current the information in this manual, or to notify any

person or organization of the updates. Please Note: For the most up-to-date version of this

manual, please see our web site at www.supermicro.com.

Super Micro Computer, Inc. ("Supermicro") reserves the right to make changes to the product

described in this manual at any time and without notice. This product, including software and docu-

mentation, is the property of Supermicro and/or its licensors, and is supplied only under a license.

Any use or reproduction of this product is not allowed, except as expressly permitted by the terms

of said license.

IN NO EVENT WILL SUPERMICRO BE LIABLE FOR DIRECT, INDIRECT, SPECIAL, INCIDENTAL,

SPECULATIVE OR CONSEQUENTIAL DAMAGES ARISING FROM THE USE OR INABILITY TO

USE THIS PRODUCT OR DOCUMENTATION, EVEN IF ADVISED OF THE POSSIBILITY OF

SUCH DAMAGES. IN PARTICULAR, SUPERMICRO SHALL NOT HAVE LIABILITY FOR ANY

HARDWARE, SOFTWARE, OR DATA STORED OR USED WITH THE PRODUCT, INCLUDING THE

COSTS OF REPAIRING, REPLACING, INTEGRATING, INSTALLING OR RECOVERING SUCH

HARDWARE, SOFTWARE, OR DATA.

Any disputes arising between manufacturer and customer shall be governed by the laws of Santa

Clara County in the State of California, USA. The State of California, County of Santa Clara shall

be the exclusive venue for the resolution of any such disputes. Super Micro's total liability for all

claims will not exceed the price paid for the hardware product.

FCC Statement: This equipment has been tested and found to comply with the limits for a Class A

digital device pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable

protection against harmful interference when the equipment is operated in a commercial environ-

ment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed

and used in accordance with the manufacturer’s instruction manual, may cause harmful interference

with radio communications. Operation of this equipment in a residential area is likely to cause harmful

interference, in which case you will be required to correct the interference at your own expense.

California Best Management Practices Regulations for Perchlorate Materials: This Perchlorate warn-

ing applies only to products containing CR (Manganese Dioxide) Lithium coin cells. “Perchlorate

Material-special handling may apply. See www.dtsc.ca.gov/hazardouswaste/perchlorate”

WARNING: Handling of lead solder materials used in this

product may expose you to lead, a chemical known to the

State of California to cause birth defects and other repro-

ductive harm.

Manual Revision 1.0a

Release Date: April 27, 2016

Unless you request and receive written permission from Super Micro Computer, Inc., you may not

copy any part of this document.

Information in this document is subject to change without notice. Other products and companies

referred to herein are trademarks or registered trademarks of their respective companies or mark

holders.

Printed in the United States of America

Produktspezifikationen

Marke:	Supermicro
Kategorie:	IM
Modell:	6038R-E1CR16N
Breite:	437 mm
Tiefe:	648 mm
Produktfarbe:	Schwarz
Höhe:	132 mm
AC Eingangsspannung:	100 - 240 V
AC Eingangsfrequenz:	50 - 60 Hz
Betriebstemperatur:	10 - 35 °C
Relative Luftfeuchtigkeit in Betrieb:	8 - 90 %
Anzahl Ethernet-LAN-Anschlüsse (RJ-45):	4
Warentarifnummer (HS):	84714100
Ethernet LAN Datentransferraten:	100,1000,10000 Mbit/s
Stromversorgung:	920 W
LED-Anzeigen:	Ja
Temperaturbereich bei Lagerung:	-40 - 70 °C
Luftfeuchtigkeit bei Lagerung:	5 - 95 %
Kupfer Ethernet Verkabelungstechnologie:	1000BASE-T, 100BASE-TX, 10GBASE-T
Prozessorfamilie:	Intel
Anzahl der unterstützten Speicherlaufwerke:	16
RAID Level:	0, 1,5, 10
USB 3.2 Gen 1 (3.1 Gen 1) Anzahl der Anschlüsse vom Typ A:	2
Gehäusetyp:	Rack (3U)
Systembus-Rate:	9.6 GT/s
Prozessorsockel:	LGA 2011 (Socket R)
Anzahl VGA (D-Sub) Anschlüsse:	1
Kompatible Prozessoren:	Intel® Xeon®
Motherboard Chipsatz:	Intel® C612
Unterstützte Arbeitsspeicher:	DDR4-SDRAM
ECC:	Ja
RAM-Speicher maximal:	1536 GB
Unterstützte Speicherlaufwerk-Schnittstellen:	Serial Attached SCSI (SAS), Serial ATA III
SATA III Anschlüsse:	10
BIOS-Speichergröße:	128 Mbit
BIOS-Typ:	EEPROM
Ethernet Schnittstellen Typ:	10 Gigabit Ethernet, Fast Ethernet, Gigabit Ethernet
LAN-Controller:	Intel X540, Realtek RTL8201N
Nachhaltigkeitszertifikate:	RoHS
Anzahl serielle Anschlüsse:	2
PCI-Express-Slots-Version:	2.0, 3.0
Trusted Platform Module (TPM):	Ja
PCI-Express x16-Slots:	2
Lüfterdurchmesser:	80 mm
Anzahl Lüfter:	2 Lüfter
Breite der Speicherschnittstelle:	72 Bit
Memory Formfaktor:	288-pin DIMM
Unterstützung für redundantes Netzteil:	Ja
Speicherspannung:	1.2 V
Anzahl unterstützter Prozessoren:	2
PCI-Express x4-Slots:	1
PCI-Express x8-Slots:	1
Zahl der DIMM Slots:	24
Unterstützte RDIMM Taktraten:	1600,1866,2133 MHz
unterstützte Speicherlaufwerksgrößen:	3.5 "
HDD Laufwerkschächte Hot-Swap:	Ja
Anzahl der installierten redundanten Netzteile:	1
IPMI LAN (RJ-45)-Anschluss:	Ja
Intel® Xeon-Serie:	E5-2600
Ungenutzter Lüfter-Support:	Ja
Intelligent Platform Management Interface (IPMI)-Unterstützung:	Ja
Trusted Platform Module (TPM) Version:	1.2
Maximaler RDIMM Speicher:	768 GB
DC Ausgangsstrom (+12 V):	75 A
Unterstützte DIMM-Modulkapazitäten:	16GB, 32GB, 4GB, 64GB, 8GB
Maximaler Cache:	45 MB
System-Bus-Typ:	QuickPath Interconnect (QPI)
BIOS-Funktionen:	APM 1.2, Plug & Play, UEFI
DC Ausgangsstrom (+5 V):	4 A
Ethernet/LAN:	Ja
Eingebautes Grafikkartenmodell:	Aspeed AST2400
Memory Spiegelung unterstützt:	Ja
