USER’S MANUAL

Revision 1.2a

SUPER

H8QGi-F

H8QG6-F

The information in this User’s Manual has been carefully reviewed and is believed to be accurate.

The vendor assumes no responsibility for any inaccuracies that may be contained in this document,

and makes no commitment to update or to keep current the information in this manual, or to notify

any person or organization of the updates. Please Note: For the most up-to-date version of this

manual, please see our web site at

www.supermicro.com.

Super Micro Computer, Inc. ("Supermicro") reserves the right to make changes to the product

described in this manual at any time and without notice. This product, including software and

documentation, is the property of Supermicro and/or its licensors, and is supplied only under a

license. Any use or reproduction of this product is not allowed, except as expressly permitted by

the terms of said license.

IN NO EVENT WILL Super Micro Computer, Inc. BE LIABLE FOR DIRECT, INDIRECT, SPECIAL,

INCIDENTAL, SPECULATIVE OR CONSEQUENTIAL DAMAGES ARISING FROM THE USE

OR INABILITY TO USE THIS PRODUCT OR DOCUMENTATION, EVEN IF ADVISED OF THE

POSSIBILITY OF SUCH DAMAGES. IN PARTICULAR, SUPER MICRO COMPUTER, INC. SHALL

NOT HAVE LIABILITY FOR ANY HARDWARE, SOFTWARE, OR DATA STORED OR USED

WITH THE PRODUCT, INCLUDING THE COSTS OF REPAIRING, REPLACING, INTEGRATING,

INSTALLING OR RECOVERING SUCH HARDWARE, SOFTWARE, OR DATA.

Any disputes arising between manufacturer and customer shall be governed by the laws of Santa

Clara County in the State of California, USA. The State of California, County of Santa Clara shall be

the exclusive venue for the resolution of any such disputes. Supermicro's total liability for all claims

will not exceed the price paid for the hardware product.

FCC Statement: Refer to Supermicro's web site for FCC Compliance Information.

California Best Management Practices Regulations for Perchlorate Materials: This Perchlorate

warning applies only to products containing CR (Manganese Dioxide) Lithium coin cells. “Perchlorate

Material-special handling may apply. See

www.dtsc.ca.gov/hazardouswaste/perchlorate”.

WARNING: Handling of lead solder materials used in this

product may expose you to lead, a chemical known to

the State of California to cause birth defects and other

reproductive harm.

Manual Revision 1.2a

Release Date: March 07, 2014

Unless you request and receive written permission from Super Micro Computer, Inc., you may not

copy any part of this document.

Information in this document is subject to change without notice. Other products and companies

referred to herein are trademarks or registered trademarks of their respective companies or mark

holders.

Printed in the United States of America

Produktspezifikationen

Marke:	Supermicro
Kategorie:	Hauptplatine
Modell:	H8QGi-F
Prozessorhersteller:	AMD
WLAN:	Nein
Breite:	419 mm
Tiefe:	330 mm
Anzahl USB 2.0 Anschlüsse:	2
Betriebstemperatur:	-40 - 70 °C
Relative Luftfeuchtigkeit in Betrieb:	8 - 90 %
Anzahl Ethernet-LAN-Anschlüsse (RJ-45):	3
Temperaturbereich bei Lagerung:	10 - 35 °C
Luftfeuchtigkeit bei Lagerung:	5 - 95 %
RAID-Unterstützung:	Ja
RAID Level:	0, 1,10
Prozessorsockel:	Socket G34
Anzahl VGA (D-Sub) Anschlüsse:	1
Motherboardformfaktor:	SWTX
Motherboard Chipsatz:	AMD SR5690
Unterstützte Arbeitsspeicher:	DDR3-SDRAM
Unterstützte Arbeitsspeichergeschwindigkeit:	1066,1333,1600 MHz
RAM-Speicher maximal:	1000 GB
Unterstützte Speicherlaufwerk-Schnittstellen:	SATA II
Anzahl PS/2 Anschlüsse:	2
Anzahl USB 2.0 Schnittstellen:	4
Chassis Intrusion Stecker:	Ja
Serielle Port-Headers:	1
BIOS-Speichergröße:	16 Mbit
BIOS-Typ:	AMI
ACPI-Version:	2.0
Ethernet Schnittstellen Typ:	Fast Ethernet, Gigabit Ethernet
LAN-Controller:	Intel® 82576
Nachhaltigkeitszertifikate:	RoHS
PCI-Express x16 (Gen 2.x)-Anschlüsse:	2
Anzahl serielle Anschlüsse:	1
SATA II Anschlüsse:	6
Wake-on-LAN bereit:	Ja
Speicherspannung:	1.35, 1.5 V
Anzahl unterstützter Prozessoren:	4
Zahl der DIMM Slots:	32
Intelligent Platform Management Interface (IPMI)-Unterstützung:	Ja
Unterstützte DIMM-Modulkapazitäten:	16GB, 1GB, 2GB, 32GB, 4GB, 8GB
PCI-Express x8 (Gen 2.x)-Anschlüsse:	2
On-board Grafikadapter-Speicher:	16 MB
Anzahl der unterstützten Prozessorkerne:	4, 8,12, 16
Ethernet/LAN:	Ja
TPM-Anschluss:	Ja
Eingebautes Grafikkartenmodell:	Matrox G200
AMD Opteron-Serie:	6000
