USER’S MANUAL
Revision 1.0
SuperServer
®
5019S-M-G1585L
5019S-MR-G1585L
2
The information in this User’s Manual has been carefully reviewed and is believed to be accurate. The vendor assumes
no responsibility for any inaccuracies that may be contained in this document, and makes no commitment to update
or to keep current the information in this manual, or to notify any person or organization of the updates. Please Note:
For the most up-to-date version of this manual, please see our website at www.supermicro.com.
Super Micro Computer, Inc. ("Supermicro") reserves the right to make changes to the product described in this manual
at any time and without notice. This product, including software and documentation, is the property of Supermicro and/
or its licensors, and is supplied only under a license. Any use or reproduction of this product is not allowed, except
as expressly permitted by the terms of said license.
IN NO EVENT WILL Super Micro Computer, Inc. BE LIABLE FOR DIRECT, INDIRECT, SPECIAL, INCIDENTAL,
SPECULATIVE OR CONSEQUENTIAL DAMAGES ARISING FROM THE USE OR INABILITY TO USE THIS PRODUCT
OR DOCUMENTATION, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. IN PARTICULAR, SUPER
MICRO COMPUTER, INC. SHALL NOT HAVE LIABILITY FOR ANY HARDWARE, SOFTWARE, OR DATA STORED
OR USED WITH THE PRODUCT, INCLUDING THE COSTS OF REPAIRING, REPLACING, INTEGRATING,
INSTALLING OR RECOVERING SUCH HARDWARE, SOFTWARE, OR DATA.
Any disputes arising between manufacturer and customer shall be governed by the laws of Santa Clara County in the
State of California, USA. The State of California, County of Santa Clara shall be the exclusive venue for the resolution
of any such disputes. Supermicro's total liability for all claims will not exceed the price paid for the hardware product.
FCC Statement: This equipment has been tested and found to comply with the limits for a Class A digital device
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with the manufacturer’s instruction manual,
may cause harmful interference with radio communications. Operation of this equipment in a residential area is likely
to cause harmful interference, in which case you will be required to correct the interference at your own expense.
California Best Management Practices Regulations for Perchlorate Materials: This Perchlorate warning applies only
to products containing CR (Manganese Dioxide) Lithium coin cells. “Perchlorate Material-special handling may apply.
See www.dtsc.ca.gov/hazardouswaste/perchlorate”.
WARNING: Handling of lead solder materials used in this product may expose you to lead, a
chemical known to the State of California to cause birth defects and other reproductive harm.
The products sold by Supermicro are not intended for and will not be used in life support systems, medical equipment,
nuclear facilities or systems, aircraft, aircraft devices, aircraft/emergency communication devices or other critical
systems whose failure to perform be reasonably expected to result in signicant injury or loss of life or catastrophic
property damage. Accordingly, Supermicro disclaims any and all liability, and should buyer use or sell such products
for use in such ultra-hazardous applications, it does so entirely at its own risk. Furthermore, buyer agrees to fully
indemnify, defend and hold Supermicro harmless for and against any and all claims, demands, actions, litigation, and
proceedings of any kind arising out of or related to such ultra-hazardous use or sale.
Manual Revision 1.0
Release Date: March 08, 2017
Unless you request and receive written permission from Super Micro Computer, Inc., you may not copy any part of this
document. Information in this document is subject to change without notice. Other products and companies referred
to herein are trademarks or registered trademarks of their respective companies or mark holders.
Copyright © 2015 by Super Micro Computer, Inc.
All rights reserved.
Printed in the United States of America
33
SuperServer 5019S-M-G1585L/MR-G1585L User's Manual
Preface
About this Manual
This manual is written for professional system integrators and PC technicians. It provides
information for the installation and use of the SuperServer 5019S-M-G1585L/MR-G1585L.
Installation and maintainance should be performed by experienced technicians only.
Please refer to the 5019S-M-G1585L/MR-G1585L server specications page on our website
for updates on supported memory, processors and operating systems (http://www.supermicro.
com).
Notes
For your system to work properly, please follow the links below to download all necessary
drivers/utilities and the user’s manual for your server.
• Supermicro product manuals: http://www.supermicro.com/support/manuals/
• Product drivers and utilities: ftp://ftp.supermicro.com
• Product safety info: http://www.supermicro.com/about/policies/safety_information.cfm
If you have any questions, please contact our support team at:
This manual may be periodically updated without notice. Please check the Supermicro website
for possible updates to the manual revision level.
Warnings
Special attention should be given to the following symbols used in this manual.
Warning! Indicates high voltage may be encountered when performing a procedure.
Warning! Indicates important information given to prevent equipment/property damage
or personal injury.
Produktspezifikationen
| Marke: | Supermicro |
| Kategorie: | Server |
| Modell: | Super 5019S-M-G1585L |
| Breite: | 437 mm |
| Tiefe: | 503 mm |
| Gewicht: | 8000 g |
| Produktfarbe: | Schwarz |
| Höhe: | 43 mm |
| AC Eingangsspannung: | 100 - 240 V |
| AC Eingangsfrequenz: | 50 - 60 Hz |
| Anzahl USB 2.0 Anschlüsse: | 2 |
| Betriebstemperatur: | 10 - 35 °C |
| Relative Luftfeuchtigkeit in Betrieb: | 8 - 90 % |
| Paketgewicht: | 13900 g |
| Anzahl Ethernet-LAN-Anschlüsse (RJ-45): | 2 |
| Ethernet LAN Datentransferraten: | 10,100,1000 Mbit/s |
| Stromversorgung: | 350 W |
| LED-Anzeigen: | HDD, LAN, Power |
| Temperaturbereich bei Lagerung: | -40 - 70 °C |
| Luftfeuchtigkeit bei Lagerung: | 5 - 95 % |
| Kupfer Ethernet Verkabelungstechnologie: | 10BASE-T, 100BASE-TX, 1000BASE-T |
| Prozessorfamilie: | Intel® Xeon® |
| Anzahl der unterstützten Speicherlaufwerke: | 4 |
| RAID Level: | 0, 1,5, 10 |
| USB 3.2 Gen 1 (3.1 Gen 1) Anzahl der Anschlüsse vom Typ A: | 4 |
| Gehäusetyp: | Rack (1U) |
| Prozessorsockel: | BGA 1440 |
| Anzahl VGA (D-Sub) Anschlüsse: | 1 |
| Kompatible Prozessoren: | Intel® Xeon® |
| Motherboard Chipsatz: | Intel® C236 |
| Unterstützte Arbeitsspeicher: | DDR4-SDRAM |
| ECC: | Ja |
| RAM-Speicher maximal: | 64 GB |
| Unterstützte Speicherlaufwerk-Schnittstellen: | Serial ATA III |
| BIOS-Speichergröße: | 64 Mbit |
| BIOS-Typ: | EEPROM |
| ACPI-Version: | 2.0 |
| Ethernet Schnittstellen Typ: | Fast Ethernet, Gigabit Ethernet |
| LAN-Controller: | Intel® I350 |
| Nachhaltigkeitszertifikate: | RoHS |
| Eingebauter Prozessor: | Nein |
| Anzahl serielle Anschlüsse: | 2 |
| PCI-Express-Slots-Version: | 3.0 |
| Lüfterdurchmesser: | 40 mm |
| Anzahl Lüfter: | 4 Lüfter |
| Breite der Speicherschnittstelle: | 72 Bit |
| Memory Formfaktor: | 288-pin DIMM |
| Speicherspannung: | 1.2 V |
| Anzahl unterstützter Prozessoren: | 1 |
| PCI-Express x8-Slots: | 1 |
| Zahl der DIMM Slots: | 4 |
| unterstützte Speicherlaufwerksgrößen: | 3.5 " |
| HDD Laufwerkschächte Hot-Swap: | Ja |
| Anzahl der Haupt-Netzteile: | 1 |
| IPMI LAN (RJ-45)-Anschluss: | Ja |
| Intel® Xeon-Serie: | E3-1585 |
| DC Ausgangsstrom (+12 V): | 29 A |
| Unterstützte DIMM-Modulkapazitäten: | 4GB, 8GB, 16GB |
| Unterstützte UDIMM Taktraten: | 1600,1866,2133 MHz |
| BIOS-Funktionen: | PCI 2.3, SMBIOS 2.3 |
| DC Ausgangsstrom (+5 V): | 15 A |
| Ethernet/LAN: | Ja |
| Eingebautes Grafikkartenmodell: | Aspeed AST2400 |
