COPYRIGHT
© 2014. SVEN
PTE. LTD
. Version 1.0 (V 1.0).
This Manual and information contained in it are copyrighted. All rights reserved.
TRADEMARKS
All trademarks are the property of their legal holders
.
NOTICE OF RESPONSIBILITY RESTRICTION
Despite the exerted eorts to make this Manual more exact, some discrepancies may ff
occur. The information of this Manual is given on “as is” terms. The author and the pub-
lisher do not bear any liability to a person or an organization for loss or damages, which
have arisen from the information contained in the given Manual
.
PURPOSE
SE-105 flush-mount double alternate switch (double-way switch) is designed for elect-
rical circuits switching.
FEATURES
• Non-ammable PC plastic casefl
• Zinc-galvanized steel core
• Copper terminals with silver coating
• Possibility to control two light sources
• Two-way switching function – one illumination device can be controlled from several
locations
• Undyed plastic color
SAFE OPERATION RULES
•
Switches should be installed and connected by qualied specialists only.fi
•
Switches should be connected according to the connection diagram given on the item
backside.
•
Avoid the item overload for its damage. The peak acceptable current value of the load
is indicated on its backside.
•
Avoid ingress of foreign objects inside the item case.
USER’S MANUAL
Dimensions, mm
Peak current, А
Peak voltage, V
Color
85 × 81
10
250
white, ivory
Double Two-Way Switch
TECHNICAL SPECIFICATIONS
Notes:
• Technical specications given in this table are supplemental information and fi
cannot give occasion to claims.
• Technical specifications are subject to change without notice due to the im-
provement of SVEN production.
SE-105
