Seite 1/2
RX Receiver x1 TX Transmitter x1 Carring & Charging Box x1
Type-C to Type-C Cable x1
External Lav Mic (With Wind Mu) x1
3.5mm TRRS Phone Cable x1
3.5mm TRS Camera Cable x1
1. Power On/ O
Power On
Method 1: The TX and RX automatically turn on after taken out from the
charging Case.
Method 2:The TX and RX automatically turn on when long press the
power button for 3 seconds, and the display screen lights up.
Power O
Method 1: After put the transmitter/receiver into the charging box, the
display screen shows [charging] and enters automatic charging. After fully
charged, the display screen goes out and automatically power o.
Method 2:The TX and RX automatically turn o when long press the
power button for 3 seconds, and the display screen lights o.
2. Pairing
Automatic Pairing
Automatically pairing after the TX/RX turns on when taken out from the
charging case.
Manual Pairing
① Long press the transmitter and receiver at the same time for 3 seconds
to power o .
② After shutdown, long press the power button of the transmitter and
receiver for 8 seconds at the same time to enter the [connecting ] state.
1. TX Transmitter
2. RX Receiver
3. Carrying & Charging Case
① External Mic Input
② Type-C Charging Port
③ On/ O Button
④ Built-in Mic
⑤ Display Screen
① Type-C Charging Port / Digital Output
② On/ O Button (Mono / Stereo / Safety Channel)
③ 3.5mm TRS Output
④ 3.5mm Monitoring Port
⑤ Display Screen
⑥ Gain Adjustment of TX A
⑦ Gain Adjustment of TX B
⑧ Magnet Pocket Clip
⑨ Contacts
① Contacts
Caring For Your SYNCO Product Product Instruction Operations
Package List
· Please keep the product in a dry, clean, dust-free environment.
· Keep corrosive chemicals, liquids and heat source away from the
product to prevent mechanics damage.
· Use only a soft and dry cloth for cleaning the product.
· Malfunction may be caused by dropping, impact of external force.
· Do not attempt to disassemble the product. Doing so voids warranty.
· Please have the product checked or repaired by authorized technicians
if any malfunctions happened.
· Failure to follow all the instructions may result in mechanics damage.
· Warranty does not apply to human errors.
Microphone G2A1 Pro
User Manual
Thank you for choosing SYNCO product.
Please read this manual carefully before use and follow all instructions
mentioned herein.
⑥ Noise Reduction
⑦ Gain Adjustment of TX
⑧ Magnet Pocket Clip
⑨ Contacts
② Power Indicator ③ Type-C Port
4. Display Screen
Recording
TX A
Gain of A TX
Audio Dynamic
Display of A TX
Noise Reduction on
TX Transmitter
RX Receiver
Muting
Recording Mode:
Mono/ Stereo/ Safety
Disconnected
Connecting
Connected
Audio Dynamic
Display
Power Indicator
TX B
Gain of B TX
Audio Dynamic
Display of TX B
Power Indicator
Disconnected Connecting
Connected
③ Successfully Connected show as the picture
*Note: Before successful connection, the transmitter channel displays
A by default. The transmitter connected to the receiver rst is the
transmitter A, and the later one is the transmitter B.
*Note: When using an external microphone, please insert it correctly
into the microphone input jack. Only TRS interface microphones are
supported.
3. Channel output connection
① 3.5mm OUT output
The receiver outputs the audio signal to the recording device via either a
3.5mm TRRS phone cable or a 3.5mm TRS camera cable. Please use the
appropriate cable according to your device.
Apple Adapter (With MFI Certication)
3.5mm TRRS Phone Cable
3.5mm TRS Camera Cable
② Type-C port digital output
The receiver Type-C port has a digital output function, which can directly
use the Type-C to Type-C cable to output mobile phones or computers
and other devices.
Mic Windshield x1
Type-C to USB-A Adapter X1
User Manual X1
Magnet x1
Produktspezifikationen
| Marke: | Synco |
| Kategorie: | Mikrofon |
| Modell: | G2 Pro |
