Seite 1/10

AWU100005GL Fold ed Size: 70 x 13 0mm C olor: Blac k

Diecut

410-4250-001A / AWU100005GL

Product Name : Portable Laptop Stand + Integrated Dock

产品名称產品名稱电脑支架带功能转换器供电 ( ): USB-C (PD )

Model ( AWU1000 SKU# : AWU100005GL型号/型號)：

PORTABLE LAPTOP STAND +

INTEGRATED DOCK

User Guide

AWU100005GL Fold ed Size: 70 x 13 0mm C olor: Blac k

Diecut

GB - Introduction

Thank you for your purchase of the Targus Portable Laptop

Stand + Integrated Dock.

Contents

• Portable Laptop Stand + Integrated Dock

• User Guide

System Requirements

Hardware

• USB-C host (Thunderbolt 3 host compatible)

Operating System

• Microsoft Windows® 10

• macOS® 10.14+

• Chrome OS

Connecting the Dock to your Laptop

This portable dock is a plug and play device. It will

automatically operate when the USB-C connector is

attached to a laptop equipped with a USB-C port.

PORTABLE LAPTOP STAND + INTEGRATED DOCK

AWU100005GL Fold ed Size: 70 x 13 0mm C olor: Blac k

Diecut

Features Description

PORTABLE LAPTOP STAND + INTEGRATED DOCK

Type-C PD adapter

Type-C Host

Gigabit Ethernet

USB-C Device

4K HDMI®

2X USB-A Device

Features

• USB 3.2 Gen 1 SuperSpeed 5Gbps Upstream Facing Host

Plug Connector

- Supports USB-C Power Delivery up to 100W Upstream*

- Supports Power Delivery 3.0

Fast Role Swap

• Two USB 3.2 Gen 1 SuperSpeed 5Gbps Downstream

Facing Type-C Device Receptacles

- One of Type-C Supports USB-C Power Delivery Pass

Through

only

- One of Type-C support SuperSpeed 5Gbps data

transmission only

• Two USB 3.2 Gen 1 SuperSpeed 5Gbps Downstream

Facing Type-A Device Receptacles

- Two Type-A port share 1.5A charging current

Troubleshooting

Device Not Working

• Make sure that the device is fully inserted into the correct

port on the portable dock.

• Plug the device into a dierent port on the USB dock. If it

still doesn’t work, test the device by connecting it directly

to your computer.

• Make sure that the device appears in Device Manager.

• Disconnect all devices from the dock and reconnect

them, one at a time. Check that each device works before

plugging in the next one.

• Each laptop USB Type-C port is equipped with over-current

protection. When a USB device draws more current than

the USB Type-C port can supply, the port will shut down.

To re-enable the port, unplug the device and go to Device

Manager or to the message in the system tray and choose

the Reset option. You can then plug the device back into

the USB port. If a shut down reoccurs, check the power

requirements of the device.

Verifying Devices are Installed

You can view the devices installed on the portable dock from

the Device Manager window in System Properties.

Press + X to open the menu, and choose Device Manager

on it.

• One Gigabit Ethernet Port

- Supports 10/100/1000Mbps

• One HDMI Port

- Supports HDMI resolution up to 4K@30Hz

- Supports USB-C DP Alt. Mode†

*USB-C PD power adapter is not included

Requires compatible PD3.0 laptops

Certain HP USB-C Laptops with 12V PD charging proﬁle may

not be supported.

† Requires compatible USB-C DP Alt Mode laptop

PORTABLE LAPTOP STAND + INTEGRATED DOCK

Produktspezifikationen

Marke:	Targus
Kategorie:	Nicht kategorisiert
Modell:	AWU100005GL
Breite:	62 mm
Tiefe:	260 mm
Gewicht:	360 g
Mitgelieferte Kabel:	USB Typ-C
Produkttyp:	Laptop-Ständer
Produktfarbe:	Silber
Höhe:	27 mm
Material:	Aluminium
Faltbar:	Ja
Höhenverstellung:	Ja
Anzahl der Höhenpostionen:	5
Warentarifnummer (HS):	84733080
Ursprungsland:	China
Unterstützt Windows-Betriebssysteme:	Ja
Mac-Kompatibilität:	Ja
USB-Ladeport:	Ja
USB 3.2 Gen 1 (3.1 Gen 1) Anzahl der Anschlüsse vom Typ A:	2
USB Datenübertragungsraten:	5000 Mbit/s
Hostschnittstelle:	USB 3.2 Gen 1 (3.1 Gen 1) Type-C
USB 3.2 Gen 1 (3.1 Gen 1) Anzahl der Anschlüsse vom Typ C:	1
USB Power Delivery:	Ja
USB-Stromversorgung bis zu:	100 W
Anpassbar:	Ja
Anzahl der unterstützten Geräte:	1
Maximale Notebook-Bildschirm-Größenkompatibilität:	15.6 "
Verbessertes Kabelmanagement:	Ja
USB-Stromversorgung Revision:	3.0
Minimale Tabletbildschirm-Größenkompatibilität:	10 "
Anzahl der anpassbaren Positionen:	5
