Seite 1/16

P/N: IDATA EXT-565

8059018364187

User's Manual

Manuale d’istruzione

HDMI EXTENDER

4K@60HZ

Technical features

POINT

HDMI EXTENDER 4K@60HZ

Dear Customer

Thank you for purchasing this product. For optimum performance and safety, please read

these instructions carefully before connecting, operating or adjusting this product. Please

keep this manual for future reference.

IMPORTANT SAFETY INSTRUCTION

INTENDED USE

We do not permit using the device in other ways like described in

this user’s manual. Use the product only in dry interior rooms. Not

attending to these regulations and safety instruction might cause

fatal accidents, injuries, and damages to persons and property.

The manufacturer/supplier assumes no liability for damages caused by failure to

comply with the intended use.

To reduce risk of electric shock, this

product should ONLY be opened

by an authorized technician when

service is required. Disconnect the

product from mains and other equipment if a problem should occur. Do not

expose the product to water or moisture.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

• Your product is not a toy and is not meant for children, because it contains small

parts which can be swallowed and can injure when used inappropriately!

• Please install the system and devices attached to it in a way that persons cannot

be injured, or objects not be damaged for example by dropping or stumbling.

• Please remove the packing materials, because children may cut themselves on

them while playing. Furthermore, there is a risk of swallowing and inhalation of

incidentals and insulating material.

• Avoid places with high temperatures, or humidity, or places which might come

into contact with water. Do not install the product close to openings of air

conditioners, or at places with an excessive amount of dust or smoke.

• Do not install the product at places subject to vibration, or oscillation.

• Do not modify and alter the product and any accessories! Do not use any

damaged parts.

• Keep enough space around all devices for a good ventilation and free motion and

to avoid damages.

• Do not mix up HDMI to RJ45 transmitter and RJ45 to HDMI receiver before

installation

• Do not unplug the deive when it is in using, keep distance from flammable and

explosive devices.

• Power supply: DC 5V/2A, usage only the supplied power unit, do not use the

power supply if it is damaged. Make sure specification matched if using 3rd party

adapters

• Static electricity will cause damage of the device, please do ESD protection when

using the device

EN - 2

WWW.TECHLY.COM

HDMI EXTENDER

4K@60HZ

Produktspezifikationen

Marke:	Techly
Kategorie:	Audio-/Video-Extender
Modell:	IDATA EXT-565
Breite:	75.5 mm
Tiefe:	85 mm
Gewicht:	691 g
AC-Netzadapter:	Ja
Produktfarbe:	Schwarz
Übertragungstechnik:	Kabelgebunden
Höhe:	16.5 mm
Betriebstemperatur:	-20 - 60 °C
Relative Luftfeuchtigkeit in Betrieb:	0 - 90 %
Typ:	AV-Sender & -Empfänger
Betriebsanleitung:	Ja
LED-Anzeigen:	Leistung
Temperaturbereich bei Lagerung:	-30 - 70 °C
HDCP:	Ja
Unterstützte Video-Modi:	2160p
Maximale Bildwiederholrate:	60 Hz
High Dynamic Range Video (HDR) Unterstützung:	Ja
Technologie mit hohem Dynamikbereich (HDR):	High Dynamic Range 10 (HDR10)
Maximale Auflösung:	4096 x 2160 Pixel
HDMI-Version:	2.0
Nachhaltigkeitskonformität:	Ja
Nachhaltigkeitszertifikate:	CE, RoHS
Anzahl der HDMI-Ausgänge:	2
Montageblöcke enthalten:	Ja
Maximal mögliche Übertragungsstrecke:	70 m
unterstütze Kabeltypen:	Cat6, Cat6a, Cat7
Bandbreite:	600 MHz
Fernbedienung (IR) output:	1
HDMI-In:	1
HDCP-Version:	2.2
Fernbedienung (IR) input:	1
RJ-45-Eingangsanschlüsse:	1
RJ-45-Ausgangsanschlüsse:	1
Händler-Code:	LKV565
IR-Blaster enthalten:	Ja
IR-Receiver enthalten:	Ja
IR-Durchgang (Pass Through):	Ja
Infrarot (IR)-Frequenzbereich:	20 - 60 kHz
Audio-Unterstützung:	Ja
