Technaxx

* User Manual

Car Power Inverter with 2 USB Ports TE19

Do not use electric charge that need higher watts than

maximum 600W continuously !

This device is only suitable for vehicle with 12V electrical

systems!

The Declaration of Conformity for this device is under the Internet link: www.technaxx.de/

(in bottom bar “Konformitätserklärung”). Before using the device the first time, please read

the user manual carefully. Service phone No. for technical support: 01805 012643 (14

cent/minute from German fixed-line and 42 cent/minute from mobile networks). Free Email:

support@technaxx.de

Keep this user manual for future reference or product sharing carefully. Do the same with

the original accessories for this product. In case of warranty, please contact the dealer or

the store where you bought this product.

Warranty 2 years

Features

⚫ Charges various electronic devices in a car (12V fixed connection needed)

⚫ 2x USB port, (max. 3A)

⚫ 2x Schuko Plug with On/Off switch

⚫ Converts 12V DC battery power into standard 230V AC (household) power,

to run a variety of electronics, e.g. tablets, smartphones, laptop computers,

game systems, small TVs, DVD/MP3 players, camping accessories, GPS

units and much more

⚫ Output power 600W (max. continuous) and 1200W (peak)

⚫ Automatic safety shutdown to secure the car battery (Alarm at ~10.5V)

⚫ High/Low voltage & overload protection

⚫ Overheating protection (built-in ventilation fan)

Technical specifications

Input voltage (DC)

12V (fixed connection) (10.5-16V)

Permanent current

58A

Input current Max

65A

Output power

600W (maximum, continuously), 1200W (peak)

Output voltage Schuko (AC)

/ AC frequency

230V / 50Hz nominal

Output Waveform

MSW ➢ The power inverter’s MSW [Modified

Sine Wave] is especially suitable for light and

heat with max. 600W.

MSW output can produce "humming" when

connected to audio equipment and is generally

unsuitable for sensitive electronics.

Nominal load efficiency

80%

Low battery voltage

shutdown and alarm

at ~10.5V

USB output ports (DC)

~30Watt (share)

AC output

2x Schuko port

Circuit protection (DC

overload)

2x 35A internal car fuse (replaceable;

suggested by technical)

Weight / Dimensions

1.2 kg / (L) 19.8 x (W) 15.9 x (H) 7.9cm

Package Contents

Car Power Inverter with 2 USB Ports TE19,

2x0.6m connection cable, User Manual

Normal use

The power inverter is intended to convert 12 V direct current voltage to

⚫ alternating current voltage 230 V/50 Hz and/or

⚫ direct current voltage max. 3000 mA (shared)

→The power inverter is only intended for permanent installation.

→This device is not intended for use by children or persons with limited mental

capacity or lacking experience and/or lacking expertise. Children should be

supervised to ensure they do not play with the device.

→This device is not intended for commercial use.

Produktspezifikationen

Marke:	Technaxx
Kategorie:	Nicht kategorisiert
Modell:	TE19
Breite:	159 mm
Tiefe:	198 mm
Gewicht:	1200 g
Mitgelieferte Kabel:	Gleichstrom
Produktfarbe:	Schwarz
Höhe:	79 mm
Energieschutzeigenschaften:	Over voltage, Overheating, Overload, Short circuit
Zweck:	Universal
Ursprungsland:	Deutschland
Menge pro Packung:	1 Stück(e)
Kabellänge:	0.6 m
Verpackungsart:	Box
Stromstecker-Typ:	Type F (CEE 7/4)
USB-Stecker:	USB Type-A, USB Type-C
Netzteiltyp:	Auto
Anzahl der USB-Anschlüsse:	2
Empfohlene Platzierung:	Auto
Ausgangsspannung:	230 V
Ausgangsleistung:	600 W
Eingangsspannung:	12 V
Für die Nutzung im Innenbereich geeignet:	Ja
Eingangsfrequenz:	- Hz
Starkstromtyp:	DC-to-AC
Kühlung:	Aktiv
Wellenform:	Sine
Output Frequenz:	50 Hz
Eingebauter Ventilator:	Ja
Spitzenstrom:	1200 W
Menge pro Behälter:	1 Stück(e)
