VIN

EN

GND

FB

VOUT

LMZ10503EXT

V

IN

V

OUT

SS

C

in

C

O

R

fbt

R

comp

C

comp

R

fbb

C

SS

1

2

3

4, EP

5

6, 7

Product

Folder

Order

Now

Technical

Documents

Tools &

Software

Support &

Community

AnIMPORTANTNOTICEattheendofthisdatasheetaddressesavailability,warranty,changes,useinsafety-criticalapplications,

intellectualpropertymattersandotherimportantdisclaimers.PRODUCTIONDATA.

LMZ10503EXT

SNVS668J–JUNE2010–REVISEDAPRIL2019

LMZ10503EXT3-APowerModuleWith5.5-VMaximumInputVoltageforDemandingand

RuggedApplications

1

1Features

1

•IntegratedShieldedInductor

•FlexibleStart-upSequencingUsingExternalSoft

Start,Tracking,andPrecisionEnable

•ProtectionAgainstIn-RushCurrentsandFaults

SuchasInputUVLOandOutputShort-Circuit

•SingleExposedPadandStandardPinoutforEasy

MountingandManufacturing

•Pin-to-PinCompatibleWith

–LMZ10504EXT(4-A/20-WMaximum)

–LMZ10505EXT(5-A/25-WMaximum)

•FastTransientResponseforPoweringFPGAs

andASICs

•ElectricalSpecifications

–15-WMaximumTotalOutputPower

–Upto3-AOutputCurrent

–InputVoltageRange2.95Vto5.5V

–OutputVoltageRange0.8Vto5V

–±1.63%FeedbackVoltageAccuracyOver

Temperature

•PerformanceBenefits

–OperatesatHighAmbientTemperatures

–LowRadiatedEmissions(EMI)Testedto

EN55022ClassBStandard

–Passes10-V/mRadiatedImmunityEMITested

toStandardEN610004-3

–PassesVibrationStandard

–MIL-STD-883Method2007.2ConditionA

–JESD22-B103BCondition1

–PassesDropStandard

–MIL-STD-883Method2002.3ConditionB

–JESD22-B110ConditionB

–CreateaCustomDesignUsingtheLMZ10503

WiththeWEBENCH

®

PowerDesigner

2Applications

•Point-of-LoadConversionsFrom3.3-Vand5-V

Rails

•Space-ConstrainedApplications

•Noise-SensitiveApplications(Suchas

Transceiver,Medical)

3Description

TheLMZ10503EXTpowermoduleisacomplete,

easy-to-use,DC-DCsolutioncapableofdrivingupto

a3-Aloadwithexceptionalpowerconversion

efficiency,outputvoltageaccuracy,lineandload

regulation.TheLMZ10503EXTisavailableinan

innovativepackagethatenhancesthermal

performanceandallowsforhandormachine

soldering.

TheLMZ10503EXTacceptsaninputvoltagerail

between2.95Vand5.5Vanddeliversanadjustable

andhighlyaccurateoutputvoltageaslowas0.8V.1-

MHzfixed-frequencyPWMswitchingprovidesa

predictableEMIcharacteristic.Twoexternal

compensationcomponentscanbeadjustedtosetthe

fastestresponsetime,whileallowingtheoptionto

useceramicorelectrolyticoutputcapacitors.

Externallyprogrammablesoft-startcapacitor

facilitatescontrolledstart-up.TheLMZ10503EXTisa

reliableandrobustsolutionwiththefollowing

features:losslesscycle-by-cyclepeakcurrentlimitto

protectforovercurrentorshort-circuitfault,thermal

shutdown,inputundervoltagelockout,andprebiased

start-up.TheLMZ10503EXTisalsofully-enabledfor

WEBENCH

®

andPowerDesignertools.

DeviceInformation

(1)(2)

PARTNUMBERPACKAGEBODYSIZE(NOM)

LMZ10503EXTTO-PMOD(7)9.85mm×10.16mm

(1)Forallavailablepackages,seetheorderableaddendumat

theendofthedatasheet.

(2)Peakreflowtemperatureequals245°C.SeeDesignSummary

LMZ1xxxandLMZ2xxxPowerModuleFamilyformore

details.

TypicalApplicationCircuit

EfficiencyV

OUT

=3.3V
