EN
Safety instructions
Intended use
This device is used to transform acoustic signals into radio signals and transmit
them. Any other use or use under other operating conditions is considered to be
improper and may result in personal injury or property damage. No liability will
be assumed for damages resulting from improper use.
Danger for children
Ensure that plastic bags, packaging, etc. are disposed of properly and
are not within reach of babies and young children. Choking hazard!
Ensure that children do not detach any small parts (e.g. knobs or the
like) from the unit. They could swallow the pieces and choke! Never let unat-
tended children use electrical devices.
Where to use the product
Never use the product
• in direct sunlight
• in conditions of extreme temperature or humidity
Tour Guide Mini Transmitter
User manual
This manual contains important information on the safe operation of the device. Read
and follow the safety advices and instructions given. Retain the manual for future refer-
ence. If you pass the device on to others please include this manual.
• in extremely dusty or dirty areas
• at locations where the unit can become wet
• near magnetic elds
Interference with other electrical equipment
Using the device near radios or TV sets may cause interference. Then increase the
distance between the devices.
General handling
• To prevent damage, never use force when operating the switches and controls.
• Never immerse the appliance in water. Just wipe it with a clean dry cloth. Do not use
liquid cleaners such as benzene, thinners or ammable cleaning agents.
Keep foreign substances from the unit!
Keep the device away from containers with liquids. Should any liquid get into the unit,
this could lead to its destruction or re. Be sure not to let any metal objects into the
unit.
Features
• 16 transmission channels selectable
• 3.5mm mini phone input socket
• Fixed built-in rechargeable lithium polymer battery (3.7V • 1300mA)
• Micro USB charging connector
• 11 hours operating time per battery charge
Operating elements
Thomann GmbH • Hans-Thomann-Straße 1 • 96138 Burgebrach • www.thomann.de • info@thomann.de DocID: 386331_22.06.2016
Using the device
1. Use an appropriate USB charging station to charge the device. A full charge of
the built-in battery takes about 6 hours.
2. Connect the cable from a microphone or line level source to the 3.5 mm mini
phone socket (6).
3. Keep the on / o button (4) pressed for two seconds to turn the unit on. The
display (2) lights up and indicates the current transmission channel.
4. To select another channel keep the +/–buttons (5, 3) simultaneously pressed
for two seconds. The CH indicator ashes on the display and the icon
disappears. Use the +/–buttons to select the desired channel.
5. To conrm the selection, briey press the on / o button (4) or wait ve
seconds for the unit to save the new channel automatically. The CH indicator
stops ashing and the icon appears again. Make sure that transmitter
and receiver are always set to the same transmission channel.
6. The volume level is set to 4 by default. 4 levels between
(4) and (full) can be adjusted. To increase the volume press the
+button (5), to reduce it press the –button (3). Briey press button 4 to mute
the device.
Technical specications
NF transmission range: 40Hz – 18kHz
Dynamic range: >80dB
Modulation: PLL, wideband FM
Carrier frequency range: UHF500 – 960MHz
Transmitting power 10mW
7. To change the input sensitivity from ‘Mic’ (default) to ‘Line’ keep the – button (3)
pressed for ve seconds until the symbol ashes.
8. When the battery is fully charged, the display shows icon is . When this
ashing, only 10% battery power are remaining and you need to charge the
battery. During charging, this icon appears:
9. The unit turns o during charging. To use it during charging, keep the on / o
button (4) pressed for two seconds to turn the unit on.
10. The unit automatically turns o after 20 minutes without input signal. To turn
the device o manually, keep the on / o button (4) pressed for two seconds.
11. The minimum distance between receiver and transmitter is 30 cm.
For the transport and protective packaging, environmentally friendly materials
have been chosen that can be supplied to normal recycling. Ensure that plastic
bags, packaging, etc. are properly disposed of. Do not just dispose of these ma-
terials with your normal household waste, but make sure that they are collected for recy-
cling. Please follow the notes and markings on the packaging.
This product is subject to the European Waste Electrical and Electronic Equip-
ment Directive (WEEE) in its currently valid version. Do not dispose of your old
device with your normal household waste. Dispose of this product through an
approved waste disposal rm or through your local waste facility. Comply with
the rules and regulations that apply in your country. If in doubt, consult your local waste
disposal facility.
Charging source: 5V micro USB
Charging time: <6hours
Dimensions (W×H×D): 40×82.612.1mm
Weight: 47g
1. Antenna
2. LCD
3. Channel selection / volume down
4. On / o switch | calling up setting parameters
5. Channel selection / volume up
6. Head set connection
7. Eyelet for lanyard
8. Micro USB charging connector
