Seite 1/8
K-10
Walkie Talkie
User Guide
US
1 Antenna.
2 Volume Knob.
3 Backl it LCD Display.
4 External Speaker. /
Microphone
5 Up Button.
6 Down Button.
7 Microphone.
8 Speaker.
9 Menu Power Buttonn. /
10 NOAA Scan Button. /
11 Call Lock Button. /
12 PTT Pull to talk Butto. ( )
13 Wrist Strap Connection.
14 Belt Clip.
15 Battery Compartment.
16 Battery Door Latch.
1
2
3
4
5
6
7
8
9
11
12
13
14
15
16
CAUTION
Product number
Frequency range
Channel number
Channel spacing
Working voltage
Frequency stability
Operating temperature range
The antenna impedance
Overall dimensions
Weight
K-10
FRS
22
12 5KHz.
3 6V.
2 5ppm.
- ℃~ ℃10 50
50Ω
160 54 41mm* *
120g
Rf power
Modulation method
Noise and harmonic
Residual Radiation
Modulation distortion
Maximum deviation
1.0W/0.5w
F3E
-40dB
≤-35dB
≤ %7
≤±5KHz
TRANSMITER
The sensitivity
Modulation receiver bandwidth
Adjacent selective
Intermodulation interference resistance
Spurious response inhibition
Audio output power
Audio distortion
≤ .0 2uV
5KHz
≥40dB
≥35dB
≥70dB
≥300mW
≤ %8
RECEIVER
Channel
1
2
3
4
5
6
7
8
9
10
11
Frequency MHz( )
Frequency MHz( )
462 5625.
462 5875.
462 6125.
462 6375.
462 6625.
462 6875.
462 7125.
467 5625.
467 5875.
467 6125.
467 6375.
Channel
12
13
14
15
16
17
18
19
20
21
22
467 6625.
467 6875.
467 7125.
462 5500.
462 5750.
462 6000.
462 6250.
462 6500.
462 6750.
462 7000.
462 7250.
1 2
( Include Antenna)
Read this operating instruction carefully before
using your two way radio, including the part on
Product Safety and Important Notice.
10
Product Features
TECHNICAL PARAMETERS
Product Features
Backlit LCD Display
1 Battery Level Indicator.
2 Roger Beep Icon.
3 VOX Icon.
4 Weather Icon.
5 Lock Icon.
6 Hi Low Power Icon. /
7 DCS CTCSS Icons. /
8 Scan Icon.
9 Weather Alert Icon.
10 DCS CTCSS Privacy Code. /
Numbers
11 Power Saver Icon.
12 Channel Numbers.
13 Receive Transmit Icon. /
14 Key Tone Icon.
1
2
3
4
5
6
11
12
13
10
8
7
9
14
Features
• 22 Channels
• 10 Channel NOAA All
Hazards Radio
• Weather Alert
• 121 Privacy Codes
( / )38 CTCSS codes 83 DCS codes
• Hands-Free Operation
( )VOX
• Scan
Channels privacy codes,
• Backl it LCD Display
• Cal l Alert
Ten selectable tones
• Button Lock
• Speaker/Microphone/Jack
• Roger Beep
Selectable On Off /
• Battery/Power Saver
• Keystroke Tones
• Battery Level Indicator
• Low Battery Audible Alert
• Auto Squelch
Installing Batteries
To install or replace batteries :
1 Remove belt clip by releasing belt clip latch and sliding clip up. .
2 Pull the battery door lock tab down to release the battery cover. .
3 Insert the cable of the supplied one lion rechargeable Into the.
battery jack.
4 Put the battery cover back into place Snap the lock tab and. .
beltclip back into place .
For charging radio s ( ) :
1 Insert the USB cable into charging jack on right of the radio. .
2 Plug the USB cable into power port. .
The radio will display flashing battery icon while charging And when .
charging complete the cycle moving will be stopped , .
Recommends your radio be turned off while being charged .
T
Press and hold the Menu /
Power button until you hear
a series of audible tones indicating the radio is on .
Your radio is now in Standby mode ready to receive ,
transmissions The radio is always in Standby mode.
except when the Talk Call or Mode Power buttons , /
are pressed .
Quick Start
1 Press and hold the Menu Power button. /
to turn on your radio .
2 Press the Menu Press the Up or Down. ,
button to select a channel .
3 Press and hold the PTT button while.
speaking into the microphone .
4 When finished talking release the PTT. ,
button and listen for a response .
3
4
Maximum range may vary and is based on unobstructed
line of sight communication under ideal conditions- - .
Both radios must be tuned to the same
channel privacy code to communicate/ .
Turning on Your Radio
