These models connect to an In-Line, Roof or Wall-
Mounted Remote Blower (sold separately). The blower
used determines the CFM. The Trade-Wind In-Line
blowers are either 836 CFM or 1266 CFM.
Before beginning installation, please thoroughly read and
become familiar with these instructions. Installation and
service must be completed by a qualified installer. Failure to
properly install this product may void the warranty.
VSL430BF
VSL436BF
VSL436-0-19BF
VSL436-0-22BF
VSL442BF
VSL442-0-19BF
VSL442-0-22BF
VSL448BF
VSL448-0-19BF
VSL448-0-22BF
VSL454BF
VSL454-0-19BF
VSL454-0-22BF
VSL460BF
VSL460-0-19BF
VSL460-0-22BF
VSL472BF
VSL472-0-19BF
VSL472-0-22BF
18"
18"
19 ¼"
22
18"
19 ¼"
22"
18"
19 ¼"
22"
18"
19 ¼"
22"
18"
19 ¼"
22"
18"
19 ¼"
22"
28 ⅜"
34 ⅜"
34 ⅜"
34 ⅜"
40 ⅜"
40 ⅜"
40 ⅜"
46 ⅜"
46 ⅜"
46 ⅜"
52 ⅜"
52 ⅜"
52 ⅜"
58 ⅜"
58 ⅜"
58 ⅜"
70 ⅜"
70 ⅜"
70 ⅜"
MODEL
FRONT TO
BACK
WIDTHCFM
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
PERFORMANCE QUALITY CUSTOMER SERVICE··
REVISED: JANUARY 1, 2024
INSTALLATION INSTRUCTIONS
USE & CARE GUIDE
VSL 400 SERIES
FOR REMOTE/IN-LINE BLOWERS
Installer:
Owner:
Please leave Installation Instructions with the range hood liner.
Please keep Installation Instructions for local electrical inspector’s use and for future reference.
WARNINGS:
IMPORTANT:
TIPS:
Must be followed carefully to avoid personal injury.
Must be followed carefully to avoid damage and incorrect installation.
Contains helpful information to facilitate installation.
WARNING! TO REDUCE THE RISK OF FIRE, ELECTRICAL SHOCK, OR INJURY TO PERSONS OBSERVE THE FOLLOWING:
a)Use this unit only in the manner intended by the manufacturer. If you have any questions, please contact the
manufacturer at the address or telephone number listed in the warranty.
b) Before servicing or cleaning unit, switch power off at service panel, lock service panel, and lock the service
disconnection means to prevent power from being switched on accidentally. When the service disconnecting means
cannot be locked, securely fasten a prominent warning device, such as a tag, to the service panel.
CAUTION:For general ventilating use only. Do not use to exhaust hazardous or explosive materials and vapors.
READ AND SAVE THESE INSTRUCTIONS
WARNING! TO REDUCE THE RISK OF A RANGE TOP GREASE FIRE:
a)Never leave surface units unattended at high settings. Boilovers cause smoking and greasy spillovers that may ignite.
Heat oils slowly on low or medium settings.
©2023 TRADE-WIND MANUFACTURING, LLC
PROVERBS 22:29
1
