Owner’s Manual

Quiet Mobile Power That Meets Federal Specification for Ambulances

Congratulations! You’ve purchased the most advanced, feature-rich Inverter/Charger designed for ambulance/EMS vehicle applications. Tripp

Lite Inverter/Chargers keep critical equipment in service by providing uninterrupted DC-to-AC power, inverted from user-supplied batteries.

Inverter/Chargers provide your equipment with utility- or generator-supplied AC electricity (filtered through premium ISOBAR® surge protec-

tion) whenever AC is available. In addition, your Inverter/Charger automatically powers your 12V DC system and recharges your connected

battery bank. Whenever the ambulance/EMS vehicle is on a call or when power blackouts, brownouts or high voltages occur, your Inverter/

Charger immediately and automatically switches over to inverting battery output to power connected AC equipment.

Better for Your Equipment Meets Safety Agency Standards

• Federal Specification KKK-A-1822E

• UL 458

Premium Protection Levels

• Built-In ISOBAR

Surge Protection

• Automatic Overload Protection

Ideal Output for All Loads

• Frequency-Controlled Output

• Automatic Load Switching

• Balanced Load Sharing

Better for Your Batteries Faster Battery Recharge

• High-Amp, 3-Stage Battery Charger (adjustable)

Critical Battery Protection

• Battery Charge Conserver (Load Sense)

• High-Efficiency DC-to-AC Inversion

Better for You Quiet, Simple, Maintenance-Free Operation

• Multi-Function Lights & Switches

• Dead Battery Startup

• Ignition Interlock

• Moisture-Resistant Construction*

Safety 2

Feature Identification 3

Operation 4-5

Configuration 5-6

Battery Selection 7

Mounting 8

Battery Connection 9

AC Input/Output Connection 10

Service/Maintenance 10

Troubleshooting 11

Warranty/Warranty Registration 11

PowerVerter

EMS Series DC-to-AC

Inverter/Chargers

Input Output

Invert: 12 VDC 120V, 60 Hz. AC

Charge: 120V, 60 Hz. AC 12 VDC

1111 W. 35th Street, Chicago, IL 60609 USA

Customer Support: (773) 869-1234

www.tripplite.com

* Inverter/Chargers are moisture-resistant, not waterproof.

Contents

WARRANTY

REGISTRATION

a chance to win a FREE Tripp Lite

product! www.tripplite.com/warranty

Important Safety Instructions

SAVE THESE INSTRUCTIONS!

This manual contains important instructions and warnings that should be followed during the installation, operation and storage of all Tripp

Lite Inverter/Chargers.

Location Warnings

• Although your Inverter/Charger is moisture resistant, it is NOT waterproof. Flooding the unit with water will cause it to short circuit

and could cause personal injury due to electric shock. Never immerse the unit, and avoid any area where standing water might

accumulate. Mounting should be in the driest location available.

• Leave a minimum of 2" clearance at front and back of the Inverter/Charger for proper ventilation. To avoid automatic Inverter/Charger

shutdown due to overtemperature, any compartment that contains the Inverter/Charger must be properly ventilated with adequate

outside air flow. The heavier the load of connected equipment, the more heat will be generated by the unit.

• Do not install the Inverter/Charger directly near magnetic storage media, as this may result in data corruption.

• Do not install near flammable materials, fuel or chemicals.

• Do not mount unit with its front or rear panel facing down (at any angle). Mounting in this manner will seriously inhibit the unit's

internal cooling, eventually causing product damage not covered under warranty.

• Install in land vehicles only.

Battery Connection Warnings

• Multiple battery systems must be comprised of batteries of identical voltage, age, amp-hour capacity and type.

• Because explosive hydrogen gas can accumulate near batteries if they are not kept well ventilated, your batteries should not be

installed (whether for a mobile or stationary application) in a “dead air” compartment. Ideally, any compartment would have some

ventilation to outside air.

• Sparks may result during final battery connection. Always observe proper polarity as batteries are connected.

• Do not allow objects to contact the two DC input terminals. Do not short or bridge these terminals together. Serious personal injury

or property damage could result.

Equipment Connection Warnings

In life support applications where failure of this equipment can reasonably be expected to cause the failure of life support

devices or to significantly affect their safety or effectiveness, such devices should be provided with at least one backup power

source by the ambulance/EMS vehicle operator.

• You may experience uneven performance results if you connect a surge suppressor, line conditioner or UPS system to the output of

the Inverter/Charger.

• Do not modify the Inverter/Charger’s plug or receptacle in a way that eliminates its ground connection. Do not use

power adapters that will eliminate the plug’s ground connection.

• Connect your Inverter/Charger only to a properly grounded AC power outlet. Do not plug the unit into itself;

this will damage the device and void your warranty.

• The Tripp Lite Inverter/Charger includes GFCI (ground fault circuit interrupter)-protected AC output receptacles.

• The main grounding lug should be connected to the vehicle chassis with a minimum #8 AWG wire.

Operation Warnings

• Your Inverter/Charger does not require routine maintenance. Do not open the device for any reason. There are no user serviceable parts inside.

• Potentially lethal voltages exist within the Inverter/Charger as long as the battery supply and/or AC input are connected. During any

service work, the battery supply and AC input connection (if any) should therefore be disconnected.

• Do not connect or disconnect batteries while the Inverter/Charger is operating in either inverting or charging mode. Operating Mode

Switch should be in the DC OFF position. Dangerous arcing may result.

Caution: These models have a failsafe AC pass-through feature where the AC output will be live (if AC input is

available) even though the operating mode switch is set to DC OFF.

Produktspezifikationen

Marke:	Tripp Lite
Kategorie:	Batterie
Modell:	EMS1250UL
Breite:	222.2 mm
Tiefe:	228.6 mm
Gewicht:	10520 g
Produktfarbe:	Weiß
Höhe:	177.8 mm
Relative Luftfeuchtigkeit in Betrieb:	0 - 95 %
Verpackungsbreite:	274.3 mm
Verpackungstiefe:	274.3 mm
Verpackungshöhe:	317.5 mm
Paketgewicht:	12290 g
Zertifizierung:	UL458,
Warentarifnummer (HS):	8504.40.9570
Ursprungsland:	China
Menge pro Packung:	1 Stück(e)
Gehäusematerial:	Polycarbonat (PC)
Anzahl Produkte pro Versandkarton:	1 Stück(e)
Gewicht Versandkarton:	12290 g
Länge des Versandkartons:	274.3 mm
Breite des Versandkartons:	274.3 mm
Höhe des Versandkartons:	317.5 mm
Netzteiltyp:	Drinnen
Anzahl der USB-Anschlüsse:	2
USB-Version:	2.0
Ausgangsstrom:	12 A
Ausgangsspannung:	120 V
Ausgangsleistung:	1250 W
Eingangsspannung:	120 V
Nachhaltigkeitszertifikate:	RoHS
Eingangsstrom:	127 A
Eingangsfrequenz:	60 Hz
Starkstromtyp:	DC-to-AC
Output Frequenz:	60 Hz
Automatische Einstellung der Ausgangsspannung:	Ja
Kapazität:	2500 W
Einstellbare Ausgangsspannung:	Ja
