Owner’s Manual

SmartRack

Enclosures

for SRCOOL3KTP Top-Rack Mounted

AC Units

Models: SR25UBAC, SR33UBAC

(Series Numbers: AGAC7006, AG-0676)

1111 W. 35th Street, Chicago, IL 60609 USA • tripplite.com/support

WARRANTY REGISTRATION

automatically entered to win an ISOBAR

surge protector in our monthly drawing!

tripplite.com/warranty

Español 19 • Français 37 • Русский 55

Important Safety Instructions 2

Overview 3

Feature Identification 4

Enclosure Installation 5

Preparation 5

Unpacking 5

Placement 7

Leveling 7

Ground Connection 8

Enclosure Configuration 9

Adding or Removing Front and 9

Rear Doors

Reversing Front Door 10

Adding or Removing Roof Panel 11

Adding or Removing Side Panels 12

Adjusting Mounting Rails and Cable 13

Management Rails

Combining (Baying) Enclosures 14

Equipment Installation 15

Installing or Removing Cage Nuts 15

Specifications 16

Storage and Service 17

Warranty and Product Registration 18

Important Safety Instructions

SAVE THESE INSTRUCTIONS

All sections of this manual contain instructions and warnings that should be followed during the installation

and use of the SmartRack Enclosures described in this manual. Read all instructions and warnings thoroughly

before attempting to move, install or use the SmartRack Enclosures described in this manual. Failure to

comply will create a risk of personal injury and property damage and may invalidate the warranty.

• Keep the enclosure in a controlled indoor environment, away from moisture, temperature extremes, flammable liquids

and gasses, conductive contaminants, dust and direct sunlight.

• Leave adequate space at the front and rear of the enclosure for proper ventilation. Do not block, cover or insert objects

into the external ventilation openings of the enclosure.

• The enclosure is extremely heavy. Use caution when handling the enclosure. Do not attempt to unpack, move or install

it unassisted. Use a mechanical device such as a forklift or pallet jack to move the enclosure in the shipping container.

• Inspect the shipping container and the enclosure for shipping damage. Do not use the enclosure if it is damaged.

• Leave the enclosure in the shipping container until it has been moved as close to the final installation location as

possible. The casters are designed for minor position adjustments within the final installation area only. The casters are

not designed for moving the enclosure over longer distances.

• The casters are not designed to provide long-term support for the enclosure after final installation. Use the levelers to

provide long-term support.

• Install the enclosure in a structurally sound area with a level floor that is able to bear the weight of the enclosure, all

equipment that will be installed in the enclosure and any other enclosures and/or equipment that will be installed nearby.

• Install the cabinet securely to the building structure, using the shipping brackets as illustrated in the Enclosure

Installation section of this manual.

• Do not push the enclosure from the side panels to move it. Pushing from the side panels will cause a tipping hazard.

• When rolling the enclosure on its casters, always push it from behind, never pull it toward you.

• A rolling enclosure can cause personal injury and property damage if not properly supervised. If rolling the enclosure

down a ramp is required, use extreme caution. Do not attempt to use ramps that have a slope steeper than 1:12.

• Use caution when cutting packing materials. The enclosure could be scratched, causing damage not covered by the

warranty.

• Save all packing materials for later use. Repacking and shipping the enclosure without the original packing materials

may cause product damage that will void the warranty.

• Do not re-ship the enclosure with additional equipment unless the enclosure was shipped with a special shock pallet

(“SP1” models only). The combined weight of the enclosure and installed equipment must not exceed the load capacity

of the pallet. Tripp Lite is not responsible for any damage that occurs during re-shipment.

• Use of this equipment in life support applications where failure of this equipment can reasonably be expected to cause

the failure of the life support equipment or to significantly affect its safety or effectiveness is not recommended.

• DANGER: STABILITY HAZARD, RACKS ARE TO BE INSTALLED BY QUALIFIED SERVICE PERSONEL ONLY.

• DANGER: RISK OF SERIOUS INJURY, SECURE THE CABINET TO THE BUILDING STRUCTURE BEFORE

MOUNTING EQUIPMENT TO THE TOP OF THE CABINET.

Produktspezifikationen

Marke:	Tripp Lite
Kategorie:	Nicht kategorisiert
Modell:	SR33UBAC
Breite:	599.9 mm
Tiefe:	1070.1 mm
Gewicht:	122907 g
Produktfarbe:	Schwarz
Höhe:	1594.62 mm
Material:	Stahl
Höchstgewichtskapazität:	1361 kg
Verpackungsbreite:	654 mm
Verpackungstiefe:	1155.7 mm
Verpackungshöhe:	1715.52 mm
Paketgewicht:	137984 g
Warentarifnummer (HS):	8517.79.0000
Ursprungsland:	China
Typ:	Freistehendes Gestell
Betriebsanleitung:	Ja
Anzahl Produkte pro Versandkarton:	1 Stück(e)
Nachhaltigkeitskonformität:	Ja
Nachhaltigkeitszertifikate:	CE, REACH, RoHS
Schrauben enthalten:	Ja
Hauptkarton GTIN (EAN/UPC):	00037332269010
Rack-Kapazität:	33U
Anzahl von Schrauben:	50
Ablageschienen:	Ja
Seitenabdeckung enthalten:	Ja
Muttern enthalten:	Ja
Anzahl der Muttern:	50
Höchstgewichtskapazität (rollend):	1021 kg
