Seite 1/44

Owner’s Manual

Power Distribution Center

Model: SUDC208V42P

1111 W. 35th Street, Chicago, IL 60609 USA • tripplite.com/support

1. Introduction 2

2. Important Safety Instructions 2

3. SUDC Sequence Of Operation 4

4. Features 5

5. Cabinet Installation 6

5.1 Preparation 6

5.2 Unpacking 6

5.3 Placement 7

5.4 Leveling 7

5.5 Ground Connection 8

6. Wiring Installation 9

6.1 Preparation 9

6.2 Installing Breakers 11

6.3 Installing Cord Sets 11

6.4 Wiring Breakers 12

6.5 Wiring Input Power 13

6.6 Powering Up 13

6.7 Powering Down 13

7. Storage & Service 14

8. Warranty and 15

Warranty Registration

Español 16

Français 31

Table of Contents

WARRANTY REGISTRATION

automatically entered to win an ISOBAR

surge protector in our monthly drawing!

tripplite.com/warranty

Tripp Lite’s SUDC208V42P Power Distribution Center accepts 3-phase input power from 120/208V, 20-60kVA UPS systems

and distributes single-phase and 3-phase output power to your data center’s equipment racks. Power distribution through

individual breakers and corresponding cord sets maximizes ﬂexibility, balances critical loads and provides branch circuit over-

current protection.

Location Warnings

• Install the Distribution Center in a controlled indoor environment, away from moisture, temperature extremes, ﬂammable

liquids and gasses, conductive contaminants, dust and direct sunlight.

• Operate the Distribution Center at indoor temperatures between 32° F and 104° F (0° C and 40° C) only.

• Allow adequate clearance around the Distribution Center for ventilation, maintenance and easy access to internal devices.

Do not block, cover or insert objects into the external ventilation openings.

• Do not place any object on the Distribution Center, especially containers of liquid.

• Do not attempt to stack the Distribution Center. Attempting to stack the Distribution Center may cause permanent damage

and create a potential for serious personal injury.

• For emergency use, install a ﬁre extinguisher rated for energized electrical equipment ﬁres (Class C rating or exact

equivalent, with a non-conductive extinguishing agent) near the Distribution Center.

Installation Warnings

• The Distribution Center is designed to hold its pre-installed breaker box only. Do NOT attempt to install rack equipment

inside the Distribution Center.

• The Distribution Center is extremely heavy. Use caution when handling the Distribution Center. Do not attempt to unpack,

move or install it unassisted. Use a mechanical device such as a forklift or pallet jack to move the Distribution Center in the

shipping container.

• Inspect the shipping container and the Distribution Center for shipping damage. If you determine that the Distribution

Center has been damaged during shipping, or if anything appears to be missing, contact Tripp Lite for assistance. Do not

use the Distribution Center if it is damaged.

• Leave the Distribution Center in the shipping container until it has been moved as close to the ﬁnal installation location as

possible. The casters are designed for minor position adjustments within the ﬁnal installation area only. The casters are not

designed for moving over longer distances.

• The casters are not designed to provide long-term support for the Distribution Center after ﬁnal installation. Use the levelers

to provide long-term support.

• Install the Distribution Center in a structurally sound area with a level ﬂoor that is able to bear the weight of the Distribution

Center and any other equipment that will be installed nearby.

• Do not push the Distribution Center from the side panels to move it. Pushing from the side panels will cause a tipping hazard.

• When rolling the Distribution Center on its casters, always push it from behind, never pull it toward you.

• A rolling Distribution Center can cause personal injury and property damage if not properly supervised. If rolling the Distribution

Center down a ramp is required, use extreme caution. Do not attempt to use ramps that have a slope steeper than 1:12.

• Do not tilt the Distribution Center or lay it on its side.

• Use caution when cutting packing materials. The Distribution Center could be scratched, causing damage not covered by

the warranty.

1. Introduction

2. Important Safety Instructions

SAVE THESE INSTRUCTIONS

All sections of this manual contain instructions and warnings that must be followed during the

installation and operation of the product described in this manual. Read ALL instructions before

attempting to move, install or wire this product. Failure to comply may invalidate the warranty and

cause serious property damage and/or personal injury.

Produktspezifikationen

Marke:	Tripp Lite
Kategorie:	Nicht kategorisiert
Modell:	SUDC208V42P
Breite:	600.2 mm
Tiefe:	1092.2 mm
Gewicht:	145600 g
Produktfarbe:	Schwarz
Höhe:	1993.9 mm
Verpackungsbreite:	1155.7 mm
Verpackungstiefe:	660.4 mm
Verpackungshöhe:	2133.6 mm
Paketgewicht:	156040 g
Ursprungsland:	Vereinigte Staaten
Typ:	Freistehendes Gestell
Anzahl Produkte pro Versandkarton:	1 Stück(e)
Gewicht Versandkarton:	156040 g
Länge des Versandkartons:	660.4 mm
Breite des Versandkartons:	1155.7 mm
Höhe des Versandkartons:	2133.6 mm
Verpackungsabmessungen (BxTxH):	705 x 1190 x 2140 mm
