Warranty

Registration:

chance to win a FREE Tripp Lite

product—www.tripplite.com/warranty

Owner’s Manual

Super Series

Surge Suppressors

1111 W. 35th Street, Chicago, IL 60609 USA

www.tripplite.com/support

The Super Series line of quality surge suppressors protects your sensitive equipment from spikes,

surges and line noise on the AC power line. Super Series “PLUS TEL” and “DELUXE” models

include RJ-style phone jacks for protection against spikes, surges and line noise on a single

telephone line. Super Series “PLUS COAX” models include F coaxial jacks for protection against

spikes, surges and line noise on a standard cable TV coaxial line.

Connecting the Super Series Surge Suppressor

Connection to AC Power Line (All Models)

The Super Series Surge Suppressor power cord should only be connected to a standard 3-wire

grounded 120 Volt AC 60 Hz outlet. The Super Series Surge Suppressor is equipped with a 4-way

mounting bracket and can be mounted on a ﬂat surface or wall. Use #8 round-head screws.

CAUTION!

DO NOT connect to an ungrounded AC outlet. DO NOT use with 2-wire

extension cords or adapters. Lack of a proper ground connection will

eliminate common-mode protection and cause small leakage potential

on the case. However, you can plug 2-wire devices into any of the surge

suppressor’s outlets. COAX models are NOT lightning arrestors. DO NOT

install COAX models in line with TV, AM, FM, amateur radio or any other

kind of outside antenna used either for reception or transmission of

radio or television signals.

201002037 93-1847.indb 1 2/8/2010 11:29:55 AM

Connection To Telephone Line (Select Models Only)

Super Series PLUS TEL and DELUXE models have two female RJ-style phone jacks that accept

connection of a wide range of equipment with male RJ-style plugs. These models provide 2-wire/

single telephone line protection. PLUS TEL and DELUXE models MUST always be the FIRST

item connected in line from the telephone jack. They MUST always be plugged into a 3-wire

grounded outlet for the telephone protection to work. Connect the phone cord from the wall jack

directly to the jack labelled “IN” (or “LINE”). Connect the phone cord from the device to be

protected directly to the jack labelled “OUT” (or “EQUIP”). The connected equipment is now

protected against spikes, surges and line noise on the telephone line.

Connection To Coaxial Line (Select Models Only)

Super Series PLUS COAX models have two “F” connector jacks that accept connection of

equipment with coaxial cables. PLUS COAX models MUST always be the FIRST item connected

in line from the coaxial jack. PLUS COAX models MUST always be plugged into a 3-wire

grounded outlet for the coaxial protection to work. Connect the coaxial cable from the wall jack

directly to the PLUS COAX jack labelled “LINE” (or “IN”). Connect the coaxial cable from

the device to be protected directly to the PLUS COAX jack labelled “EQUIP” (or “OUT”). The

connected equipment is now protected against spikes, surges and line noise on the coaxial cable.

Connecting the Super Series Surge Suppressor continued

Connecting Equipment

Features

After you have properly connected your Super Series Surge Suppressor to the AC line (and

telephone and coaxial line, if applicable), you can connect the AC power cords of equipment to

the surge suppressor. DO NOT OVERLOAD the surge suppressor. Connect loads having a total

current draw of up to 15 amps. Each outlet can handle up to 15 amps, but do not exceed a total

load of 15 amps for all outlets. If the circuit breaker trips, remove overload and depress circuit

breaker button to reset.

Circuit Breaker (All Models)

If the current draw of the equipment connected to the Super Series Surge Suppressor exceeds 15

amps for longer than a few seconds, the circuit breaker will open (trip) to prevent any possible

damage. When the circuit breaker trips, the plunger will be extended. Allow the breaker to cool

for one minute before depressing the plunger to reset.

Illuminated “ON/OFF” Switch (Select Models)

With the Super Series Surge Suppressor plugged into a 120V AC outlet, this switch will

illuminate RED whenever moved to the “ON” position. This indicates 120V AC power is present

at the unit’s AC receptacles.

Diagnostic Indicator Lights

There are up to three LEDs on the front panel that indicate various operating parameters when the

unit is plugged into a live 120V AC outlet.

• Protection Present (Green LED) (All Models)

Indicates the surge suppression components are intact and providing full protection against

spikes and surges. This LED should be illuminated anytime the “ON/OFF” switch is

turned ON and power is present as indicated by the lighted power switch. If the Protection

Present LED does not illuminate, then some of the surge suppression components are not

functioning and the unit should be returned for repair as soon as possible. You may still use

the unit; however, connected equipment will be protected from spikes and surges at a lesser

level than normal.

201002037 93-1847.indb 2 2/8/2010 11:29:55 AM

Features continued

• Line “OK” (Green LED) (Select Models)

Indicates 120V AC power is present with no wiring faults detected. When this LED is

illuminated, AC power is safe for connected equipment.

• Fault (Red LED) (Select Models)

Indicates a wiring fault has been detected. If this LED illuminates at anytime the unit is

plugged in, the fault should be repaired by a qualiﬁed electrician as soon as possible. This

LED indicates that phases are reversed, ground is missing or some other sort of wiring error

exists in the circuit the Super Series Surge Suppressor is plugged into. The Fault detector

circuitry will identify most common wiring faults, but will not necessarily detect every

possible type of fault.

NOTE! If the Fault indicator light illuminates, carefully check the AC receptacle the Super Series

Surge Suppressor is plugged into. The receptacle must be tight and securely grounded. A loose AC

receptacle may cause the Fault indicator light to illuminate. It must be understood that this Red LED

indicates the presence of a wiring fault, but does not indicate the exact nature of the fault. Therefore,

a qualiﬁed electrician should be contacted to make necessary repairs.

NOTE! The Fault indicator light will illuminate to indicate that the Super Series Surge Suppressor’s

surge suppression components have been compromised as a result of surge damage. If, after

inspection by a qualiﬁed electrician, a wiring fault is not detected, the Fault indicator light may

be indicating that the surge suppression components have been compromised as a result of surge

damage. Even if the surge suppressor is providing AC power at all of the receptacles, it may not

provide its total rated surge suppression as outlined in the “Speciﬁcations” section. Should you

require service, visit www.tripplite.com/support.

CAUTION!

DO NOT drill into any part of the housing. DO NOT open the housing.

There are no user-serviceable parts inside.

LIFETIME LIMITED WARRANTY

Seller warrants this product, if used in accordance with all applicable instructions, to be free from original defects in material and

workmanship for its lifetime. If the product should prove defective in material or workmanship within that period, Seller will repair or

replace the product, in its sole discretion. Service under this Warranty can only be obtained by your delivering or shipping the product

(with all shipping or delivery charges prepaid) to: Tripp Lite, 1111 W. 35th St., Chicago, IL 60609. Seller will pay return shipping charges.

The warranties of all TRIPP LITE Surge Suppressors are null and void if they have been connected to the output of any UPS system.

The warranties of all TRIPP LITE UPS Systems are null and void if a surge suppressor has been connected to its output receptacles.

THIS WARRANTY DOES NOT APPLY TO NORMAL WEAR OR TO DAMAGE RESULTING FROM ACCIDENT, MISUSE, ABUSE

OR NEGLECT. SELLER MAKES NO EXPRESS WARRANTIES OTHER THAN THE WARRANTY EXPRESSLY SET FORTH

HEREIN. EXCEPT TO THE EXTENT PROHIBITED BY APPLICABLE LAW, ALL IMPLIED WARRANTIES, INCLUDING ALL

WARRANTIES OF MERCHANTABILITY OR FITNESS, ARE LIMITED IN DURATION TO THE WARRANTY PERIOD SET

FORTH ABOVE; AND THIS WARRANTY EXPRESSLY EXCLUDES ALL INCIDENTAL AND CONSEQUENTIAL DAMAGES.

(Some states do not allow limitations on how long an implied warranty lasts, and some states do not allow the exclusion or limitation of

incidental or consequential damages, so the above limitations or exclusions may not apply to you. This Warranty gives you speciﬁc legal

rights, and you may have other rights which vary from jurisdiction to jurisdiction.)

TRIPP LITE; 1111 35th St.; Chicago, IL 60609

WARNING: The individual user should take care to determine prior to use whether this device is suitable, adequate or safe for the use

intended. Since individual applications are subject to great variation, the manufacturer makes no representation or warranty as to the

suitability or ﬁtness of these devices for any speciﬁc application.

WARRANTY REGISTRATION

Visit www.tripplite.com/warranty today to register the warranty for your new Tripp Lite product. You’ll be automatically entered into a

drawing for a chance to win a FREE Tripp Lite product!*

* No purchase necessary. Void where prohibited. Some restrictions apply. See website for details.

201002037 93-1847.indb 3 2/8/2010 11:29:55 AM

Produktspezifikationen

Marke:	Tripp Lite
Kategorie:	Nicht kategorisiert
Modell:	TR-6FM
Breite:	88.9 mm
Tiefe:	241.3 mm
Gewicht:	750 g
Mitgelieferte Kabel:	Telefon (RJ-11)
Produktfarbe:	Grau
Höhe:	44.4 mm
Material:	Kunststoff
Stecker:	NEMA 5–15P
AC Eingangsfrequenz:	50 - 60 Hz
Verpackungsbreite:	152.4 mm
Verpackungstiefe:	317.5 mm
Verpackungshöhe:	50.8 mm
Paketgewicht:	1040 g
Zertifizierung:	UL, FCC, cUL/CSA
Ursprungsland:	China
Kabellänge:	1.83 m
Reaktionszeit:	0.000001 ms
LED-Anzeigen:	Ja
Ein-/Ausschalter:	Ja
Anzahl Produkte pro Versandkarton:	20 Stück(e)
Gewicht Versandkarton:	19100 g
Länge des Versandkartons:	533.4 mm
Breite des Versandkartons:	317.5 mm
Höhe des Versandkartons:	342.9 mm
Kabelfarbe:	Grau
Nachhaltigkeitszertifikate:	RoHS
Drahtlos:	Nein
Wandmontage:	Ja
RJ-11 ports Quantität:	2
Hauptkarton GTIN (EAN/UPC):	10037332010619
Anzahl der AC-Ausgänge:	6 AC-Ausgänge
AC-Steckertypen:	NEMA 5–15R
EMI/RFI Lautstärkefilter:	Ja
Nominale Eingang Spannung:	120 V
Spitzenstrom:	1800 W
Klemm-Spannung:	140 V
Überspannungsschutz-Funktionen:	Fax, Modem, Telephone
Nominale Stromabgabe:	15 A
Anstieg der Energiemenge:	3040 J
