Seite 1/2
TOM-60SW(B)-N 11.2 3 3/4 x 2 11.3 535 63
1/4 5/8 1/2 x 34 x 41
Horizontal Open Display Cases
Model CU./FT.
# of Bottom
Shelves HP AMPS
Crated
Weight
(
lbs.
)
L x D x H
(
inches
)
Project :
Model # :
Item # : Qty :
Available W/H :
Approval :
4184 E. Conant St.
Long Beach, CA 90808
Tel. 310-900-1000
Fax. 310-900-1077
www.turboairinc.com
Slim Line
Glass Side Panel
Model : TOM-60SW(B)-N
NO PLUMBING REQUIRED
more durable, efficient,beautiful
This product is equipped with a
fine mesh filter to the front of the
condenser to catch dust, and a
rotating brush that moves up and
down daily to remove excess
buildup outward and away.
Patented Self-Cleaning Condenser
* For the , please allow 8-10 weeks lead time for shipping.‘Stainless Steel Front Panel (SF)’ options
Ver.20171114
TOM-60SB-N
TOM-SB-SF-N
Stainless steel front panel
available (optional)
TOMD-HB
TOM-60SW-N
Q
Top display dry case
available (optional)
Self-Cleaning Condenser
The accumulation of dust in the condenser can cause the failure or
breakdown of refrigerators. Refrigerators run normally until they reach a
certain level of accumulation. At some point, when they are over the limit,
their performance drops quickly resulting in damage to, or disposal of the
stored products inside. The Self-Cleaning Condenser device keeps the
condenser clean and prevents system failure by automatically brushing
daily.
Hydrocarbon refrigerants (R-290)
With innovative and eco-friendly technology, Turbo Air brings you hydro-
carbon refrigerators designed to meet the new standards of the EPA and
DOE in 2017. Hydrocarbon refrigerants do not deplete the ozone layer and
have very low contribution to global warming (ODP-0, GWP-3).
Modern design
By integrating great contours with durable structures, our modern style
product designs are user-friendly while maintaining the highest product
visibility and aesthetics. Safety reinforced tempered glass front shield and
side walls optimize the merchandiser’s display effects of fresh salads,
sandwiches, desserts and beverages. Its elegant contemporary euro design
will enhance any store application. Ideal for eye-catching displays and
convenient access with fast service in high traffic areas.
Standard back-guard improves airflow
300 series stainless steel interior standard
including back wall and deck pans
Stainless steel solid shelves standard
Perforated interior back wall & top for improved
air flow
Foamed with polyurethane, high-density cell
insulation (CFC free)
Front air intake and rear air discharge
FEATURES & BENEFITS
TOM-60SB-N
2 YEA
R
(
U.S. A on ly )
5 YEAR
Compressor
WARRANT Y
(
U.S
.A
only)
C US
Turbo Air : 800-627-0032
Warranty : 800-381-7770
GK : 800-500-3519
AC : 888-900-1002
631/4 (1607mm)
603/4 (1543mm)
631/4 (1607mm)
345/8 (880mm)
PLAN VIEW
Horizontal Open Display Cases
(unit : inch)
TOP VIEW
FRONT VIEW
Slim Line
Glass Side Panel
Model : TOM-60SW(B)-N
411/2 (1054mm)
331/2 (850mm)
411/2 (1054mm)
345/8 (880mm)
251/2 (648mm)
337/8 (861mm)
7
(178mm)
13 (330mm)
7
(178mm)
91/8
(251mm)
21/2 (64mm)
21/2 (64mm)
SIDE VIEW
ELECTRICAL DATA
DIMENSIONAL DATA
Voltage
Plug Type
Full Load Amperes
Compressor HP
Refrigerant
Net Capacity (cu. ft.)
Ext. Length Overall (in.)
Ext. Depth Overall (in.)
Ext. Height Overall (in.)
Int. Length Overall (in.)
Int. Depth Overall (in.)
Int. Height Overall (in.)
Net Weight (lbs.)
Gross Weight (lbs.)
# of Bottom Shelves
Shelf Size (L x D)(in.)
115/60/1
NEMA 5-20P
11.3
3/4 x 2
R-290
11.2
631/4 (1607mm)
345/8 (880mm)
411/2 (1054mm)
60
3/4 (1543mm)
24 (610mm)
13 (330mm)
440
535
3
603/4 x 7 (Top)
60
3/4 x 14 (Middle)
60
3/4 3/4 x 9 (Low)
Design and specifications subject to change without notice.
Actual shipping weight may differ due to extra packing materials for product protection.
Ver.20171114
2 Year Parts and Labor Warranty
Additional 3 Year Warranty on Compressor
Anti-corrosion coated evaporator
Simple plug-in installation
Patented self-contained system, no plumbing required
White and black color come standard
Solar powered digital thermometer
Digital electronic thermostat with defrost control
LED interior lighting
Recommended operating conditions:
TOM models are designed to operate in an environment where
temperature & humidity do not exceed 75°F and 55% respectively.
Units should not be installed near HVAC vents, fans or doorways that will
disrupt the air curtain and compromise the function of the cabinet.
Air curtain models will run most efficiently when completely loaded with product.
OPTIONAL ACCESSORIES :
STANDARD FEATURES :
4” caster, ½” diameter & 13 TPI: G8F6500101 (non-brake),
G8F6500201 (w/ brake)
Top display dry cases: TOMD-60LW(B) (Low), TOMD-60HW(B) (High)
Night cover: NCT-60-W (White), NCT-60-B (Black)
* Night cover option won’t be able to apply on TOM-LW(B)/SW(B)-N models
if TOMD-L/HW(B) dry case is already installed on top of the unit.
Stainless steel front panel available: TOM-SW(B)-SF-N (extra lead time will
apply, please call factory for more details to order)
2 YEAR
(
U.S. A on ly )
5 YEAR
C
ompressor
WA
RRANT Y
(U.S.A
only
)
C US
