Seite 1/2

Wiring Sequences

Controller Illustration

TP-SC24-20 Solar

Charge Controller

PWM 12/24V 20A

User Manual

1) First: Connect the battery first, please choose cable size accordingly.

2) Second: Connect the solar panel

3) Last: Connect the load wiring to the load (if necessary)

PV BAT LOAD WARN SET

Thanks for your purchase of our solar charge controller!

PARAMETER Unit

CHG BAT LOAD

1.Display Section

Description of tools and symbols

Controller Features

Marks &

Tools

Item

Description

High

Voltage

Danger

Mark

High

voltage

might

exist

inside

the

controller. Service only by professional.

Heating

Caution

Controller surfaces may be hot in operation.

Do not

dispose

trash.

Wire

Stripper

For

wire

stripping.

Volt

Meter

check

the

positive/negative

connection,

and

check

current

other

electrical

value.

Anti-static

Glove

avoid

controller

damage

caused

static

electricity

from

human

body.

tape

the

wiring

joint

for

afety.

Screwdriver

mount the controller

ICON

Status

Current

system

working

status

Parameter

value

for

selected

item

Selected

Item

Current

selected

item

This device is a PWM 12/24V 20A solar battery

charge controller ideal for many applications. Its

flush mount design makes it a perfect solution for

RV’s, boats and remote power applications. Please

be sure to read this manual to familiarize yourself

with the features and operation of the controller.

The PWM solar charge controller is used for solar charging

of batteries from a 12V or 24V solar panel. It features a low

voltage disconnect control on the load output to prevent

battery damage. It has an LCD screen to display solar,

battery and load voltages and currents.

f) All common battery types are supported: AGM, GEL,

Flooded Lead Acid and Li-Ion.

g) 12/24V Battery Voltage Auto Select for all lead acid

types of battery.

h) PWM 3 Phase Charging – Equalize, Boost, Float.

i) Supports 20A on solar input and 20A on load output.

a) User-friendly key press operation; simpler and easier.

b) 5V USB power port for charging mobile devices.

c) Multiple load output control mode selections: light

control, light + time, test & debug, manual and

always-on modes are supported.

d) Industrial grade design for operation in harsh

environments.

e) Full range of electrical protections; Solar & battery

disconnect protection, battery over-discharge, system

over-voltage, etc.

Produktspezifikationen

Marke:	Tycon Systems
Kategorie:	Nicht kategorisiert
Modell:	TP-SC24-20
Display-Typ:	LCD
Breite:	122 mm
Tiefe:	70 mm
Gewicht:	200 g
Internationale Schutzart (IP-Code):	IP30
Steuerung:	Tasten
Höhe:	34.5 mm
Eingebautes Display:	Ja
Betriebstemperatur:	-25 - 65 °C
Zertifizierung:	CE, RoHS
Ausgangsstrom:	20 A
Nachhaltigkeitszertifikate:	RoHS
Ladespannung:	- V
