PAGE 1 OF 210624 IH-6517

1-800-295-5510

uline.com

ELECTRIC UNIT HEATERS

H-6517, H-6518

SPECIFICATIONS

HEATER RATING

AND VOLTAGE

BTU PER

HR.

PHASE

CONTACTOR

BUILT-IN

MOUNTING HEIGHT

MIN. DISTANCE

FROM HORIZONTAL

AIR THROW

MOUNTING

HOLE

TO WALL

VERTICAL

INSTALLATION

HORIZONTAL

INSTALLATION

MIN.MAX.MIN.MAX.

H-6517

* 5000 W @ 240 V

4165 W @ 240 V

3332 W @ 240 V

2500 W @ 240 V

17,065

14,215

11,365

8,533

1No6'11'6'8'18'**13"

* 3750 W @ 208 V

3123 W @ 208 V

2500 W @ 208 V

1874 W @ 208 V

12,799

10,659

8,533

6,396

1No6'11'6'8'18'**13"

H-6518

* 7500 W @ 240 V

6250 W @ 240 V

5000 W @ 240 V

3750 W @ 240 V

25,598

21,331

17,065

12,799

1Yes6'11'6'8'18'**13"

* 5625 W @ 208 V

4685 W @ 208 V

3750 W @ 208 V

2812 W @ 208 V

19,198

15,990

12,799

9,598

1Yes6'11'6'8'18'**13"

* Heater is shipped from factory wired for these wattages. Heater can be field adjusted to the other wattages.

(See Heat Output Adjustments, page 5)

**48" when heater air flow is between 45° downward and vertical.

TOOLS NEEDED

HARDWARE NEEDED

Phillips

Screwdriver

Needle Nose PliersPliersElectric Drill

and 1/4" Bit

Adjustable Wrench

• Enough 10 gauge (or thicker) insulated copper

conductor wire (with ground) to run power from the

breaker/fuse to the heater

NOTE: Only use copper wire rated at least 167°F.

Do not use aluminum wire.

• Proper size fuses and circuit breakers in accordance

with the National Electrical Code. See Heat Output

Adjustments, page 5.

• 3/8 x 2" Wood Screw Lag Bolt x 2

• 3/8" Washer x 2

• Wire connectors sized to application

NOTE: Conduit may be required. (See Figure 1)

Check local electrical codes. If wiring is run in

conduit, ensure there is enough flexible conduit

to allow heater to be turned, if necessary.

1234

Figure 1

Conduit

Flexible

Conduit

Flexible

Conduit

Connector

Flexible NM

Cable Connector

Flexible

NM Cable

Conduit

Connector

Para Español, vea páginas 8-14.

Pour le français, consulter les pages 15-21.
