Seite 1/15

WEEE Number

: 80133970

T8 BATTEN FITTING

This marking indicates that this

product should not be disposed of

with other household wastes.

Caution, risk of

electric shock.

TECHNICAL DATA

IN CASE OF ANY QUERY/ISSUE WITH THE PRODUCT, PLEASE REACH OUT TO US AT: SUPPORT@V-TAC.EU FOR MORE

PRODUCTS RANGE, INQUIRY PLEASE CONTACT OUR DISTRIBUTOR OR NEAREST DEALERS. V-TAC EUROPE LTD.

BULGARIA, PLOVDIV 4000, BUL.L.KARAVELOW 9B

WARNING!

1. Please make sure to turn o the power before starting the installation.

2. Installation should only be done by a certiﬁed electrician.

3. Proper grounding should be ensured throughout the installation.

4. For Indoor use only

T8 BATTEN FITTING

INSTRUCTION MANUAL

Model

Rating

Body

Type

Operation

Temperature

Dimension

(LxWxH)

Input Power

VT-16010 IP20 Iron -20 to +40°c 615x45x50mm AC:200-240,50/60Hz

VT-12020 IP20 Iron -20 to +40°c

1225x45x50mm

AC:200-240,50/60Hz

VT-15020 IP20 Iron -20 to +40°c 1520x45x50mm AC:200-240,50/60Hz

SKU

POWER

6052

1x22W

(max)

1x18W

(max)

1x10W

(max)

6054

6056

Tubes not included

INTRODUCTION & WARRANTY

Thank you for selecting and buying V-TAC product. V-TAC will serve you the best. Please read

these instructions carefully before starting the installation and keep this manual handy for

future reference. If you have any another query, please contact our dealer or local vendor from

whom you have purchased the product. They are trained and ready to serve you at the best.

The warranty is valid for 2 years from the date of purchase. The warranty does not apply to

damage caused by incorrect installation or abnormal wear and tear. The company gives no

warranty against damage to any surface due to incorrect removal and installation of the

product. The products are suitable for 10-12 Hours Daily operation. Usage of product for 24

Hours a day would void the warranty. This product is warranted for manufacturing defects only.

INSTALLATION DIAGRAM

1. Switch o the power before

starting the installation

9. Switch on the

power to test the

light.

NOTE: Compatible with V-TAC LED Tubes - Single side power supply

8. Insert LED Tube

7. Fix the front cover of the ﬁtting.

2. Remove the front cover of the ﬁtting.

4. Install the ﬁtting on the wall

(Accessories not included).

3. Fix the wire through the ﬁtting.

5. Install the lamp holders as shown.

6. Connect the wires as indicated on the

ﬁtting.

T8 BATTEN FITTING

Produktspezifikationen

Marke:	V-TAC
Kategorie:	Erleichterung
Modell:	VT-16010
Produktfarbe:	Weiß
Internationale Schutzart (IP-Code):	IP20
Zertifizierung:	EMC, LVD
Gehäusematerial:	Aluminium
Empfohlene Platzierung:	Büro
Länge (mm):	600 mm
Gehäusefarbe:	Weiß
Nachhaltigkeitszertifikate:	RoHS
Lichtfarbe:	Tageslicht
Glühlampenform:	Rohr
