Seite 1/4

INSTRUCTION MANUAL

ENERGY STORAGE POWER SUPPLY

IN CASE OF ANY QUERY/ISSUE WITH THE PRODUCT, PLEASE REACH OUT TO US AT: SUPPORT@V-TAC.EU

FOR MORE PRODUCTS RANGE, INQUIRY PLEASE CONTACT OUR DISTRIBUTOR OR NEAREST

DEALERS. V-TAC EUROPE LTD. BULGARIA, PLOVDIV 4000, BUL.L.KARAVELOW 9B

Model VT-606

Battery capacity

568Wh

Wireless output 15W

Dimension 275x170x200mm

DC Input Port

20V 5A

(Support 12-24V)

12.5V 8A

AC output

500W

Pure Sine Wave/

Peak 1000W

USB output port

5V2.4A, QC3.0,

USB-C 65W

Battery

Lithium Electronic

Battery

Battery cycle ≥800

Work Temperature

-10~40°C

Charging Temperature 0~40°C

Net Weight 5.4Kg

Auxiliary Charge

Output

Thank you for selecting and buying V-TAC Product. V-TAC will serve you the best.

Please read these instructions carefully & keep this user manual handy for future

reference. If you have any another query, please contact our dealer or local vendor

from whom you have purchased the product. They are trained and ready to serve you

at the best.

INTRODUCTION

TECHNICAL DATA

Multi-Language Manual QR CODE

Please scan the QR code to access the manual

in multiple languages.

WARNING

PACKAGING LIST

1. Please make sure to turn oﬀ the power before starting the installation.

2. Installation must be performed by a qualiﬁed electrician.

3. a. Please read all instructions before using this product.

4. In order to reduce the risk, close supervision is required when using this product near

children.

5. The use of accessories recommended or sold by non professional product manufacturers

may lead to the risk of electric shock.

6. When the product is not in use, please pull the power plug out of the product socket.

7. It is forbidden to dismantle the product, which may lead to unpredictable risks such as ﬁre,

explosion or electric shock.

8. Do not use damaged wires or plugs or damaged output cables to use the product, which

may cause electric shock.

9. Please charge the product in a well ventilated place. Do not restrict the ventilation of the

product in any way.

10. Please put the product in a well ventilated and dry place to avoid the risk of electric

shock due to water intrusion.

11. It is forbidden to expose the product to ﬁre or temperature higher than 130°C, which may

lead to ﬁre, explosion and other safety accidents.

12. It is forbidden to use or place the product under high temperature (direct hot sunshine or

hot car interior), otherwise the internal battery may overheat, catch ﬁre or function failure,

shorten the service life and other risks.

13. Please charge the product every three months to prevent the battery from running out.

Caution, risk of electric

shock.

This marking indicates that this

product should not be disposed

of with other household wastes.

PAP

Power supply

Car Charger

AC Power

Adapter

User Guide

User guide

DC: DC working indicator

AC: AC work indicator

Over operating temperature warning

/ overload warning / short circuit warning

Flashing is low voltage warning

PARTS & DESCRIPTION

PRECAUTIONS FOR USE

1: High temperature protection. When the temperature is greater than or equal to 75°C, the

machine will start the automatic protection and prohibit input and output. When the tempera-

ture is less than 75°C, it will return to normal.

2: Power on / oﬀ key. Please click the power key to turn oﬀ the power.

3: When the indication of DC, USB and AC lights up, it means that the output port has been

turned on, and the corresponding equipment can be powered.

4: When not using the power output port, please press 1,2,7,11 or power key to turn oﬀ the

power to save power.

5: At low temperature, the battery capacity of the product may be aﬀected. The product can

be charged in the temperature range of 0-40 degrees, and the equipment can be powered in

the temperature range of -10 degrees to +40 degrees.

6: For the ﬁrst time, it is recommended to fully charge the battery to avoid the inconvenience

caused by insuﬃcient power.

Display percentage of input power

Output power

Input power

DC charging indicator

DC output indic orat

DC input charging

DC output on key,

click on / oﬀ

AC working indic orat

AC output on key,

click on / oﬀ

USB output indicator

USB output key,

click switch

Power click on / oﬀ

QC 3.0

output

USB-C 65 W

output

USB 2.0

output

LED light: click normally on, click SOS mode

again, and click LED light oﬀ again

Wireless charging switch: USB is on, wireless

charging works normally, USB is oﬀ, and

wireless charging stops working
