Seite 1/2
IN CASE OF ANY QUERY/ISSUE WITH THE PRODUCT, PLEASE REACH OUT TO US AT: SUPPORT@V-TAC.EU
FOR MORE PRODUCTS RANGE, INQUIRY PLEASE CONTACT OUR DISTRIBUTOR OR NEAREST DEALERS.
V-TAC EUROPE LTD. BULGARIA, PLOVDIV 4000, BUL.L.KARAVELOW 9B
INSTRUCTION MANUAL
LED BACKLIT PANEL
INTRODUCTION & WARRANTY
MULTI-LANGUAG
MANUAL QR CODE
Please scan the QR code
to access the manual in
multiple languages.
Thank you for selecting and buying V-TAC product. V-TAC will serve you the best. Please read these instructions
carefully before starting the installation and keep this manual handy for future reference. If you have any another
query, please contact our dealer or local vendor from whom you have purchased the product. They are trained
and ready to serve you at the best. The warranty is valid for 5 years from the date of purchase. The warranty
does not apply to damage caused by incorrect installation or abnormal wear and tear. The company gives no
warranty against damage to any surface due to incorrect removal and installation of the product. The products
are suitable for 10-12 Hours Daily operation. Usage of product for 24 Hours a day would void the warranty. This
product is warranted for manufacturing defects only.
TECHNICAL DATA
MODEL VT-61036
SKU 23624, 23625
POWER 36W
LUMENS 4320 Lm
BEAM ANGLE 110°
CRI ≥80
PF ≥0.9
LIFE SPAN 30,000 Hours
ON/OFF CYCLE >20,000 Times
IP RATING IP20
OPERATING
TEMPERATURE -10°C to +35°C
INPUT POWER AC: 220-240V, 50/60Hz
DIMENSION 595x595x33 mm
This marking indicates that this
product should not be disposed
of with other household wastes.
Caution, Risk of electric shock
INSTALLATION INSTRUCTION
1
3 4
2
1. Make a hole ceiling
AC:220-240V DRIVER
+
-
PANEL
LIGHT
3. Wiring the DC cable of the panel to the
powersupply. And wiring the AC source
cable to the powersupply. 4. Turn on the switch,
test the fixture light on.
2. Put up the panel onto the ceiling
• Please make sure to turn o the power before starting the installation.
• Installation should only be done by a certified electrician.
• Terminal block not included.
• The light source of this luminaire is not replaceable, when the light
source reaches its end of life the whole luminaire should be replaced.
• If the external flexible cable or cord of this luminaire is damaged, it
shall be exclusively replaced by the manufacturer or his service agent
or a similar qualified person in order to avoid a hazard.
• Proper grounding should be ensured throughout the installation.
• For Indoor use only.
WARNING
