1 9471026

ISSUE 1

VIP-VAF

MULTI-COLOR FLASHER

INTRODUCTION

The VIP-VAF Multi-Color Flasher is a private

mode notification appliance that provides bright

flasher functionality with both power and activation

provided by the IP network. Multiple flashers may

be synchronized to flash in unison.

SPECIFICATIONS

Features

• Cost effective and versatile solution to

applications requiring visual alerts or flashers

• Power over Ethernet Plus (PoE+) 802.3at Class

4 compatible

• 7 flash patterns and 10 brightness levels

•16 High brightness, Red, Green, Blue, White

LEDs, with up to 300 lumens each

•360° x 180° Coverage

• Night Ring functionality in conjunction with other

Valcom IP speakers

• Synchronized flashing when used with additional

Valcom Flashers

Activation Methods

• Valcom Site Manager server

• Valcom Interactive Console

• Valcom Group Page

• SIP Phone Call

Input/Output

• One Normally Open Supervised Input

•One Normally Open Relay Output,

Form A, Rated 1A @ 24 Vdc

Dimensions / Weight

• 5.76"H x 5.76"W x 3.10"D

(14.6cm H x 14.6cm W x 7.9cm D)

•1.2 lbs. (0.54 kg)

Nominal Power Requirements

• Via 802.3at PoE+ Class 4, 20W max

Environment

• Temperature: -40 to +123°F (-40 to +50°C)

• Humidity: 0 to 85% non-precipitating

• Ingress Protection: IP66 rated

Suitable for indoor or outdoor installation when

properly installed.

INSTALLATION

Operation

The VIP-VAF provides private mode notification

via network connection.Activation of the Flasher

is triggered by including the VIP-VAF as a

member of a Valcom IP Paging group. The VIP-

VAF can also operate as a visual Night Ring

device in conjunction with a SIP PBX and can

provide audio Night Ring to other Valcom IP

speakers when activated. Interface to customer

telephone system can be via SIP registration to a

Voice over IP (VoIP) telephone system, or FXO

port (when used with a Valcom Enhanced Station

Port).

Mounting

The VIP-VAF is designed for single-gang, double-

gang or octagon electrical box mounting or

mounting directly to a solid surface.

NOTE: The VIP-VAF can synchronize with

other Valcom IP Flashers, but not with other

manufacturers’ devices. Therefore, it must not

be installed where the flash from other, non-

Valcom flashers may be seen.
