Table of ContentsRev. 2/13/2024 ALL-T-(1/35)-GPT-ST-L MANUAL

Table of ContentsCopyright 2019 Vestil Manufacturing Co. Page 1 of 15

ALL TERRAIN PALLET TRUCKS

MODELS: ALL-T-1-GPT-ST-L & ALL-T-35-GPT-ST-L

Receiving Instructions

After delivery, remove the packaging from the product. Inspect the product closely to

determine whether it sustained damage during transport. If damage is discovered, record a complete

description of

iton the bill of lading. If the product is undamaged, discard the packaging.

NOTE:The end-user is solely responsible for confirming that product design, use, and maintenance

comply with laws, regulations, codes, and mandatory standards applied where the product is used.

Technical Service & Replacement Parts

For answers to questions not addressed in these instructions and to order replacement parts, labels,

andaccessories, call our Technical Service and Parts Department at (260) 665-7586. The department

can also becontacted online athttps://www.vestil.com/page-parts-request.php.

Electronic copies ofInstruction Manuals

This instruction manual may be downloaded from https://www.vestil.com/page-manuals.php

VESTIL MANUFACTURING COMPANY

2999 North Wayne Street, P.O. Box 507, Angola, IN 46703

Telephone: (260) 665-7586 -or-Toll Free (800) 348-0868

Fax: (260) 665-1339

http://www.vestil.com/e-mail: info@vestil.com

Table of Contents

Page

Specifications…………………...…………......................................................................................................

2

National Standards…………………………………………………..………………………………………...……

3

Signal Words……….……………….................................................................................................................

3

Safety Instructions.........................................................................................................................................

3

Operating the Truck…………………….……….............................................................................................

4

Fork Carriage Controls……...………………………………………………………………………………….......

4 - 5

Lifting and Transporting Loads………….……………………………………………………………………...….

5

Parking Brake……………………………….....................................................................................................

6

Disengaging the Transmission (Neutral Mode)...……………………………………………………….……...

6

Record of Satisfactory Condition…………………………………………………………………………………

6

Inspections and Maintenance……………………………………………………………………………...…….

6 - 7

Exploded View and Bill of Materials………………………...…………………………………………………....

8 - 9

Rear Wheel Axle Assembly Exploded Views and Bills of Materials…………………………………………

10

Steering Handle Subassembly Exploded View and Bill of Materials…………………………………….…

11

Power Unit Subassembly Exploded View and Bill of Materials………………………..………………….…

12

Sprocket Drive Subassembly, Right Side, Exploded View and Bill of Materials……………..……………

13

Sprocket Drive, Subassembly, Left Side, Exploded View and Bill of Materials..…………..………...……

13

Labeling Diagram…….……………………………………………………………………………………………...

14

Limited Warranty…………………………………………………………………………………..………………...

15
