TABLE OF CONTENTSRev. 3/28/2022 CBFC, MANUAL

TABLE OF CONTENTSCopyright 2022 Vestil Manufacturing Co. Page 1 of 13

CBFC Counterbalanced Floor Crane

Receiving Instructions

After delivery,remove the packaging from the product. Inspect the product closely to determine

whether it sustained damage during transport. If damage is discovered, record a complete description

of it on the bill of lading. If the product is undamaged, discard the packaging.

NOTE:The end-user is solely responsible for confirming that product design, use, and maintenance

comply with laws, regulations, codes, and mandatory standards applied where the product is used.

Technical Service & Replacement Parts

For answers to questions not addressed in these instructions and to order replacement parts, labels,

and accessories, call our TechnicalService and Parts Department at (260) 665-7586. The department

can also be contacted online at http://www.vestilmfg.com/parts_info.htm

.

Electronic Copies of Instruction Manuals

Additional copies of this instruction manual may be downloaded from

https://www.vestil.com/page-

manuals.php.

V

ESTIL

M

ANUFACTURING

C

ORP

.

2999 North Wayne Street, P.O. Box 507, Angola, IN 46703

Telephone: (260) 665-7586 -or-Toll Free (800) 348-0868

Fax: (260) 665-1339

www.vestilmfg.com[email protected]

Table of Contents

Page

Signal Words….………………………………………………………………………………………………….

2

Safety Instructions………………………………………………..……………………………...………………

2

CBFC-500 & CBFC-1000 Exploded View & Bill of Materials……………………..………………………

3

CBFC-500 Rated Loads for Specified Boom Lengths…….………………………………………………

4

CBFC-1000 Rated Loads for Specified Boom Lengths …….……………………….……….………….

5

CBFC-2000 Exploded View & Bill of Materials………………….…..………………………..……………

6

CBFC-2000 Rated Loads for Specified Boom Lengths…………..………………………....……………

7

Manual Hydraulic Pump Exploded View & Bill of Materials.……………………………………...……

8

Operating the Manual Hydraulic Pump………………..………………………………………..…………

9

Using the Crane………………………………………………………………………...…………………….…

9

Air Purging Procedure…………………………………………………………………………………………

10

Boom Length Adjustment…………………..…………………………………………………………………

10

Record of Satisfactory Condition……………………………………………………………………………

10

Inspections & Maintenance………………………………………………………………………………….

10 - 11

Troubleshooting…………………………………………………………………………………………………

11 - 12

Labeling Diagram……...……………………………………..…………………………………………..……

12

Limited Warranty…...……………………………………………………………………………………………

13
