Table of ContentsRev. 5/23/2025 FHSN, MANUAL.doc

Table of ContentsCopyright 2022 Vestil Manufacturing Co. Page 1 of 17

FHSN-Series Knockdown Steel Fixed Height Gantry Cranes

Receiving Instructions

After delivery, remove the packaging from the product. Inspect the product closely to

determine whether it sustained damage during transport. If damage is discovered, record a

complete description of

iton your bill of lading. If the product is undamaged, discard the

packaging.

NOTE: The end-user is solely responsible for confirming that product design, use, and

maintenance comply with laws, regulations, codes, and mandatory standards applied where the

product is used.

Technical Service & Replacement Parts

For answers to questions not addressed in these instructions and to order replacement parts,

labels,

and accessories, call our Technical Service and Parts Department at (260) 665-7586. The

department

can also becontacted online athttps://www.vestil.com/page-parts-request.php.

Electronic Copies of Instruction Manuals

Additional copies of this instruction manual may be downloaded from

https://www.vestil.com/page-manuals.php.

Vestil Manufacturing Co.

2999 North Wayne Street, P.O. Box 507, Angola, IN 46703

Telephone: (260) 665-7586 -or-Toll Free (800) 348-0868

Fax: (260) 665-1339

Web: www.vestil.com e-Mail: info@vestil.com

Table of Contents

Page

Table of Figures

Page

Specifications……...………………....….

2

FHSN Exploded Views………………………………………..

4 - 8

Signal Words….……………………..……

2

Fig. A: FHSN-2-10, FHSN-2-15, & FHSN-2-20……………….

4

Safety Instructions……………………..

3

Fig. B: FHSN-4-10, FHSN-4-15, & FHSN-4-20……………….

5

National Standards………………….…

3

Fig. C: FHSN-6-10, FHSN-6-15, & FHSN-6-20…………….….

6

Assembling the Crane……….…….....

9 - 12

Fig. D: FHSN-8-10, FHSN-8-15, & FHSN-8-20……………….

7

Using the Crane……………………..…

13

Fig. E: FHSN-10-10 & FHSN-10-15………………………...…

8

Loading the Crane………………...….

13

Installing the Optional Festoon Kit……………………….

15

Record of Satisfactory Condition….

13

Inspections & Maintenance…………..

14

Labeling Diagram…………………….

16

Limited Warranty………………...……

17
