Seite 1/51
Rev. 0213 EPT, Manual.doc
Copyright 2013 Vestil Manufacturing Corp. Page 1 of 51
EPT-SERIES ELECTRIC PALLET TRUCKS
OPERATION AND MAINTENANCE MANUAL
Receiving instructions:
After delivery, IMMEDIATELY remove the packaging from the product in a manner that preserves the
packaging and maintains the orientation of the product in the packaging; then inspect the product closely to
determine whether it sustained damage during transport. If damage is discovered during the inspection,
immediately
record a complete description of the damage on the bill of lading. If the product is
undamaged, discard the packaging.
NOTES
:
1) Compliance with laws, regulations, codes, and non-voluntary standards enforced in the location where
the product is used is exclusively the responsibility of the owner/end-user.
2) VESTIL is not liable for any injury or property damage that occurs as a consequence of failing to apply either:
a) Instructions in this manual; or b) Information provided on labels affixed to the product.
Neither is Vestil
responsible for any consequential damages sustained as a result of failing to exercise sound judgment
while assembling, installing, using or maintaining this product.
TABLE OF CONTENTS PAGE TABLE OF FIGURES PAGE
Safety Principles 2 Fig. 1A EPT Main Body Components 5
Product Introduction 2 Fig. 1B EPT-30 (optional) Scale Components 6
Safety Guidelines 3 Fig. 2 EPT-30 Hydraulic Cylinder Assembly 7
Removing EPT from Pallet 3 - 4 Fig. 3 EPT-30 Drive Wheel Assembly 8
Use, 1
st
Inspection, & Functions Tests 20 Fig. 4A EPT-30 Fork & Carriage 9
Operation 20-21 Fig. 4B EPT-30 Fork & Carriage (optional) Scale 10
Lifting & Transporting Loads 21 Fig. 5A Control Yoke & Handle Components 11-12
Batteries & Charger 21-22 Fig. 5B Control Yoke & Handle (optional) Scale 13-14
Fig. 6 Hydraulic Pump & Motor Assemblies 15
Troubleshooting
23-48 Fig. 7 EPT-45 Main Housings & Supporting Structure 16
Changing Cylinder 28-31 Fig. 8 Removable Battery Box & Components 16
Changing Throttle Assy. 32-36 Fig. 9 EPT-45 Cylinder & Fuse Panel 17
Changing Motor Assy. 37-39 Fig. 10 EPT-45 Fork & Carriage Assemblies 18
Replacing Forward/Reverse Contactor 40-42 Fig. 11 Function Controls, Gauges, & Safety Features 19
Changing Battery Charger 43-46 Maintenance & Inspections 49-50
Adding Quencharcs 47-48 Markings 51
VESTIL MANUFACTURING CORP.
2999 North Wayne Street, P.O. Box 507, Angola, IN 46703
Telephone: (260) 665-7586 -or- Toll Free (800) 348-0868
Fax: (260) 665-1339
www.vestilmfg.com e-mail: sales@vestil.com
Rev. 0213 EPT, Manual.doc
Copyright 2013 Vestil Manufacturing Corp. Page 2 of 51
PRODUCT INTRODUCTION
Specifications for each of the 4 models appear in the table below:
Net Wt. Fork Size Service
MODEL (lbs.)
(W x L) in inches Range (in.)
Capacity
(lbs.)
Overall Size
(W X L x H) in inches
EPT-2047-30 660 20in. X 47in. 3.2 to 7.8 3,000 28 x 65 x 49
EPT-2547-30 671 25in. x 47in. 3.2 to 7.8 3,000 28 x 65 x 49
EPT-2048-45 990 20in. x 48in. 3.4 to 8 4,500 30x 78.5 x 49
EPT-2748-45 1012 27in. x 48in. 3.4 to 8 4,500 30x 78.5 x 49
Vestil Manufacturing Corp. created this manual to acquaint owners and users of our electric pallet trucks
with safe operation and maintenance procedures. Employers are responsible for instructing employees to
use the product properly. Employees and any other persons, who might foreseeably use, repair, or
perform maintenance on the EPT must read and understand every instruction BEFORE using the device.
Cart operators should have access to the manual at all times and should review the directions before each
use. Contact Vestil for answers to any question you have after reading the entire manual.
Although Vestil diligently strives to identify foreseeable hazardous situations, this manual cannot address
every conceivable danger. The end-user is ultimately responsible for exercising sound judgment at all times.
SAFETY PRINCIPLES
We offer four types of electric pallet truck (EPT): two 3,000 pound (~1364kg) capacity models, the EPT-2047-
30 and 2547-30, and two 4,500 pound (~2045kg) capacity models, the EPT-2048-45 and 2748-45. Each unit
conforms to the generalized specifications disclosed in this manual and fulfills our demanding standards for
quality, safety and durability.
Vestil Manufacturing Corp. recognizes the critical importance of workplace safety. Each person who might
participate in operation or maintenance of the product must read this manual. Read the entire manual and fully
understand the directions BEFORE using or performing maintenance on the cart. If you do not
understand an instruction, contact Vestil for clarification. Failure to adhere to the directions in this
manual might lead to serious personal injury or even death.
Vestil is not liable for any injury or property damage that occurs as a consequence of failing to apply the safe
operation and maintenance procedures explained in this manual or that appear on labels affixed to the product.
Furthermore, failure to exercise good judgment and common sense may result in property damage, serious
personal injury, or death, and also are not the responsibility of Vestil.
This manual applies the hazard identification methods suggested for instruction manuals by the American
National Standards Institute (ANSI). In accordance with ANSI guidelines for hazard identification language, this
manual classifies personal injury risks and situations that could lead to property damage with SIGNAL WORDS.
These signal words announce an associated safety message. The reader must understand that the signal word
chosen indicates the seriousness of that hazard according to the following convention:
Identifies a hazardous situation which, if not avoided, WILL result in DEATH or SERIOUS
INJURY. Use of this signal word is limited to the most extreme situations.
Identifies a hazardous situation which, if not avoided, COULD result in DEATH or
SERIOUS INJURY.
Indicates a hazardous situation which, if not avoided, COULD result in MINOR or
MODERATE injury.
Identifies practices not related to personal injury, such as operation that could damage the cart.
No safety alert symbol (equilateral triangle enclosing an exclamation point) accompanies this
signal word.
Thank you for purchasing an electric pallet truck (“EPT,” “pallet truck,” “truck,” or
“unit”) offered by Vestil Manufacturing Corporation (“Vestil”). Our EPT’s are durable,
high-quality products that combine safety features and low-maintenance mechanisms.
Despite the product’s relatively simple mechanics, all personnel must familiarize
themselves with the safe operation instructions provided in this manual.
