Rev. 7/27/2017 WTJ-E, MANUAL

Copyright 2017 Vestil Manufacturing Corp. Page 1 of 11

WTJ-E Series Vehicle Mounted Jib Cranes

Instruction Manual

Receiving instructions:

After delivery, remove the packaging from the product. Inspect the product closely to determine whether it

sustained damage during transport. If damage is discovered, record a complete description of it on the bill of

lading. If the product is undamaged, discard the packaging.

NOTE:

The end-user is solely responsible for confirming that product design, installation, use, and maintenance

comply with laws, regulations, codes, and mandatory standards applied where the product is used.

Table of Contents

Specifications……….………………………………………………………………………………………………………….. 2

Exploded parts diagrams and bills of materials…………………………………………………………………………….. 3 - 4

Signal words……………………………………………………………………………………………………………………. 5

Hazards of improper use………………………………………………………………..…………………………………….. 5

Assembling the crane………………………………………………………………………………………………………….. 5 – 6

Storage configuration………………………………………………………………………………………………………….. 6

Installing the crane…………………………………………………………………………………………………………….. 7

Function tests…………………………………………………………………………………………………………………… 7

Using the crane…………………………………………………………………………………………………………………. 8

Boom angle adjustments………………………………………………………………………………………………………. 9

Boom length adjustments……………………………………………………………………………………………………… 9

Inspections………………………………………………………………………………………………………………………. 9

- 10

Troubleshooting Guide……………………………………………………………………………………….......................... 10

Labeling diagram………………………………………………………..……………………………………………………… 10

Limited warranty………………………………………………………………………………………………………………… 11

Vestil Manufacturing Corp.

2999 North Wayne Street, P.O. Box 507, Angola, IN 46703

Telephone: (260) 665-7586 -or- Toll Free (800) 348-0868

Fax: (260) 665-1339

www.vestilmfg.com e-mail:

HU[email protected]U

WTJ-E-15-3-AC WTJ-E-15-3-DC
