PRODUCT MANUAL
Designed, Manufactured and Supported in the USA
SECURITY & COMMUNICATION SOLUTIONS
Features
TheK-1275Entry Phone is a two-way, handsfree
telephone with 12 buttons for calling individual
residences in an apartment building with an
integrated 125 KHz Proximity Card Reader. It also
has a built-in color CCTV video camera. The
rugged stainless steel faceplate has a printed
directory housed in a waterproof, scratch-resistant
lens. Each button is beside the tenants name in the
directory so there are no confusing codes to deal
with. Calling a particular tenant is as easy as
pressing a single button. The K-1275has a built in
speed dialer that can handle up to 12 primary
phone numbers, each with 22 digits. If there is no
answer at the first number, a second number can
be called automatically. Once the tenant answers
their phone, a single touch tone command can
activate the door strike relay. For “no phone line”
applications, the K-1275is compatible with the
C-3000no CO (phone line) controller.
The K-1275-EWPshares all of the features of the
K-1275in addition to Enhanced Weather
Protection (EWP) for outdoor installations where
the unit is exposed to precipitation or
• Built-in high resolution analog NTSC color video camera with wide
viewing angle, tilt/swivel adjustments and wide operating
temperature: -40°F to 140°F
• Built-in 125KHz 26-bit Wiegand proximity card reader with LED, beep
card read confirmation, and EWP board protection
• Compatible with the following Viking Proximity Cards and Fobs: PRX-
C, PRX-C-ISO, PRX-FOB andLRT-4 (DOD# 198 & 226)
• Vandal Resistant Features:14 gauge louvered 316 stainless steel
faceplate with permanent laser etched graphics, heavy duty metal
keypad and T-10 Torx security mounting screws.
• Weather Resistant Features:Marine grade 316 stainless steel
faceplate and screws. Internally sealed keypad. Mylar speaker. Self-
draining mic mount. Faceplate, keypad, mic and speaker gaskets.
• Designed to meet IP66 Ingress Protection Rating (see DOD 859)
• Operates on 12 to 24 volts AC/DC
• 12 speed dial buttons (22 digits each)
• 12 alternate number positions (22 digits each)
• One button operation (no call button)
• Hang up on CPC, busy, silence, time-out or dial tone
• Touch tone restriction from microphone
• Integral relays for camera control and door strike
• Works with C-1000Bfor increased security
• Works with C-3000for “No CO” (phone line) operation
• 50 keyless entry codes
• Postal lock input
• Optional VE-5x10surface mount box, sold separately (DOD 424)
• Small apartment buildings
• Professional buildings
• Gated communities
Power: 12 to 24 Volts AC or DC, 12VDC adapter provided
Proximity Card Reader Power:5 to 14V DC @ 60mA maximum
Note: To assure operation during a power outage, a UPS
should be used.
Dimensions: 127mm x 254mm x 63.5mm (5" x 10" x 2.5")
Shipping weight: 2.2 kg (4.8 lbs.)
Standard K-1275 Environment: -34° C to 65° C (-30° F
to 150° F) with 5% to 95% non-condensing humidity
K-1275-EWP Environment:-34° C to 65° C (-30° F to
150° F) with up to 100% condensing humidity
Relay Contact Rating:
Door Strike: 5A @ 30VDC/250VAC maximum
Camera: 0.5A @ 125 VAC, 1.0A @ 30VDC
Connections: (19) gel-filled butt connectors (3M
Scotchlok UR2)
Applications
Specifications
www.vikingelectronics.com
Information: (715) 386-8861
VIKING
condensation. EWP products feature foam rubber
gaskets and boots, sealed connections, gel-filled
butt connectors, as well as urethane or thermal
plastic potted circuit boards with internally sealed,
field-adjustable trim pots and DIP switches for easy
on-site programming.
(shown in optional
VE-5x10-SS, not included)
12 Button Apartment Entry Phone with Built-In
Door Strike Relay, Card Reader & Camera
“Brushed 316 Stainless Steel”
(similar to brushed nickel)
K-1275Series
Entry Phones with Keypads,
Proximity Card Readers
and Color Camera
July 5, 2017
Produktspezifikationen
| Marke: | Viking |
| Kategorie: | Zugangskontrollsystem |
| Modell: | K-1275 |
| Eingebaute Lautsprecher: | Ja |
| Breite: | 127 mm |
| Tiefe: | 63.5 mm |
| Gewicht: | 2200 g |
| Produktfarbe: | Edelstahl |
| Höhe: | 254 mm |
| Eingebautes Display: | Nein |
| Betriebstemperatur: | -34 - 65 °C |
| Relative Luftfeuchtigkeit in Betrieb: | 5 - 95 % |
| Zertifizierung: | FCC Part 68\nFCC Part 15 |
| Gehäusematerial: | Edelstahl |
| LED-Anzeigen: | Status |
| Eingangsspannung: | 250 V |
| Eingangsstrom: | 5 A |
| einegbaute Tastatur: | Ja |
| Tastatur Anzahl der Tasten: | 12 |
| Autentifizierungstyp: | Access chip/card, Password |
| Zugriffschip/Kartenleser: | Ja |
| Zugriffscodeleser: | Ja |
