Installation Instructions for

Secure the mounting plate to the junction box.

Connect the fixture ground wire to a suitable ground in accordance to local electrical codes.

Connect the white fixture wire to the neutral power line wire with a wire nut.

Connect the black fixture wire to the hot power line wire with a wire nut.

Mount the fixture onto the mounting plate and secure it in place with the fixture screws.

Install the candle tube(s) by placing it over the socket(s).

Install the shade(s) by placing it over the socket(s) then use the shade ring tool to tighten the shade ring onto the socket.

Screw the lamp(s) into the socket(s). Refer to the label on the socket for Max Wattage Information.

1

2

3

4

5

1.0

T1111-TV1122-TV1133V

T1111,T1122,TV1133VV

6

7

8

GPI:ENERALRODUCTNFORMATION

These fixtures are intended to be installed utilizingcompliant junctionNEC

boxes.

This product is safety listed for damp locations.

Incandescent lamps may be dimmed with a standard incandescent dimmer.

LEDLEDlamps may be dimmed with adimmer.Consult lamp manufacturer for

additional information.

1A

JUNCTION BOX

Logan 1,2 and 3 LightVanity

Vanity

CAUTIONRISK OF FIRE-

This product must be installed in accordance with the

applicable installation code by a person familiar with the

construction and operation of the product and the hazards

involved.

Use minimum 90°c supply conductors.

MOUNTING

PLATE

3

4

5

FIXTURE

SCREW

LAMP

6

7

8

SHADE RING

SHADE

SHADE RING

TOOL

CANDLE TUBE

SOCKET

FIXTURE

5
