Vitek VTC-T4B4HR8MD Bedienungsanleitung

Lies die bedienungsanleitung für Vitek VTC-T4B4HR8MD (1 Seiten) kostenlos online; sie gehört zur Kategorie Sicherheitskamera. Dieses Handbuch wurde von 6 Personen als hilfreich bewertet und erhielt im Schnitt 4.9 Sterne aus 3.5 Bewertungen. Hast du eine Frage zu Vitek VTC-T4B4HR8MD oder möchtest du andere Nutzer dieses Produkts befragen? Stelle eine Frage

VITEKCCTV.COM

(888) VITEK-70

VTC-T4B4HR8MD

8 MegaPixel [4K] 4-in-1 Indoor / Outdoor HDA Dual Voltage

(12VDC/24VAC) Motorized Varifocal Bullet Camera

KEY FEATURES

• 1/2.5” 8.51 Megapixel Sony® Starvis™ Progressive Scan CMOS Sensor

• NDAA Compliant

• 15fps live view @ 3840 x 2160 [4K]

• True Day/Night by IR Cut Filter

• HD-TVI / HD-CVI / AHD / 960H CVBS Video Output (Selectable)

• Motorized 2.7~13.5mm MegaPixel IR Corrected Auto Focus Varifocal Lens

• 4 Integrated High Power Dynamic IR LEDs with up to 165’ IR Range

• XD-DNR Noise Reduction (3D & 2D-DNR)

• True Wide Dynamic Range (WDR)

• Auto White Balance

• IP66 Weather Resistance

• Supports Control over COAX (CoC)

• Over 1500’ HD Video Transmission (Depending on cable characteristics and integrity)

• Optional Junction Box Available (VT-TJB04A)

• 12VDC / 24VAC Dual Voltage Operation

• 3 Year Warranty

ACCESSORIES

RECORDERS

VT-TJB04 - Optional Junction Box for Cable Management

(888) VITEK-70 • WWW.VITEKCCTV.COM

SPECIFICATIONS

Image Sensor1/2.5” 8.51 Megapixel Sony® Starvis™ Progressive Scan

CMOS Sensor

NDAA CompliantYes

Signal SystemPAL/NTSC

Effective Pixels3840 (H) × 2160 (V) [4K]

Resolution /

Video Output

Up to 8MP

TVI: 4MP@25fps, 4MP@30fps, 5MP@20fps, 8MP@12-5fps, 8MP@15fps

AHD: 4MP@30fps, 5MP@20fps, 8MP@15fps

CVI: 4MP@25fps, 4MP@30fps, 8MP@15fps

Lens2.7~13.5mm Motorized Varifocal Lens

Day/NightTrue Day/Night by ICR (Extern, Color, B&W, Auto)

Min. IIIumination0.001 Lux @ f2 (B/W) / 0.1Lux @ F2.0 (Color) /

0 Lux (IR ON)

IR LEDs4x High Power Dynamic IR LEDs

IR DistanceUp to 165’

DSS (Sens-Up)OFF / X2 ~ X32

S/N Ratio≥50dB (AGC Off)

WDRTrue Wide Dynamic Range (WDR)

Digital Noise ReductionXD-DNR (2D-DNR & 3D-DNR)

White Balance Auto / Present / External / Manual

BLC, DeFogYES - Adjustable

Privacy Mask16 Programmable Areas

Motion Detection4 Programmable Areas

Control over COAX (CoC)YES

Transmission DistanceUp to 1500’ (Depending on cable characteristics & integrity)

Power InputDual Voltage: 12VDC / 24VAC

Power Consumption<7.5W

Power Consumption

(12VDC)

600mA (IR ON) / 300mA (IR OFF)

Power Consumption

(24VAC)

300mA (IR ON) / 150mA (IR OFF)

Weather Resistance IP66

Storage Temperature

Working Conditions

-4°~122°

14°~122° / Humidity 90% or less

Weight31.04 oz. / 1.94 lbs. / 880g

Dimensions2.97” × 3.07” × 11.17” (75.4 × 78.2 × 283.7mm)

Pair with VITEK Transcendent

Series 5-in-1 Digital Video Recorders

Supporting HD-TVI / AHD / CVI / IP /

960H Cameras!

DIMENSIONS

VT-TR4VPK

Video and Power Balun

Transmitter / Receiver

Pair for HD-TVI / AHD

/ CVI for Distances

Up to 1000’

VT-TR4K

Passive Video Balun

Transmitter /

Receiver Pair for HD-

TVI / AHD / CVI for

Distances Up to

1440’
