VITEKCCTV.COM

(888) VITEK-70

VTD-THD8R2

Transcendent Series 8 MegaPixel [4K] Indoor/Outdoor

4-in-1 Fixed Vandal Dome Camera

Image Sensor

Signal System

Effective Pixels

Resolution

Video Output

Frame Rate

Lens

Day/Night

Min. IIIumination

IR LEDs

IR Distance

Dynamic (Smart) IR

S/N Ratio

Wide Dynamic Range

Digital Noise Reduction

Auto White Balance

Back Light Compensation

Control over COAX (COC)

Transmission Distance

Power Input

Power Consumption

Weather / Impact

Operation Conditions

Weight

Dimensions

1.25” 8.0 MegaPixel Progressive Scan CMOS Sensor

NTSC/PAL

3840 x 2160

HD-TVI & AHD: 8.0 MegaPixel / CVI: 4.0 MegaPixel /

CVBS: 960H

HD-TVI / AHD / CVI / CVBS (Selectable)

8MP@15fps / 5MP@20fps / 4MP@30fps

2.8mm - Fixed

True Day/Night by ICR

Color: 0.001 [email protected], AGC ON / B/W: 0 lux

(with IR ON)

16 SMD Type IR

Up to 65’

YES

≥52 dB (AGC Off)

D-WDR (Digital Wide Dynamic Range)

3D-DNR

YES (AWB)

YES (BLC)

YES

Up to 1500’ (Depending on Cable Characteristics

and Integrity)

12VDC

IR Off: < 2W / IR On: < 5W

IP67 + IK10

-4°~122° / 10%~90% Humidity

21.16oz / 1.32lb / 600g

4.59” × 3.54” (117mm × 90mm) Dia × H

SPECIFICATIONS

KEY FEATURES

Pair with VITEK Transcendent

Series 5-in-1 Digital Video Recorders

Supporting HD-TVI / AHD / CVI / IP /

960H Cameras!

• 1/2.5” 8MegaPixel [4K] Progressive Scan CMOS image sensor

• High Definition Analog (HDA) / HD-TVI / AHD / HD-CVI / CVBS

• 8MP@15fps, 5MP@20fps, 4MP@30fps High Res, True Color

• Supports OSD Menu

• Digital Wide Dynamic Range (D-WDR)

• 2.8mm Fixed Iris Lens

• 16 SMD Type IR LEDs with up to 65’ IR Range

• True Mechanical Day/Night function by ICR

• 3D-DNR (Digital Noise Reduction)

• IP67 Weather Resistance + IK10 Impact

• Supports Control over COAX (CoC)

• Over 1500’ HD Video Transmission (Depending on cable characteristics

and integrity)

• Optional Junction Box (VT-TJB03A), Wall Mount (VT-TWMT3) and

In-Ceiling Semi Flush Mount (VT-TFMT-S) Availablem [See Below for Other

Options]

• 12VDC Operation

• 3-Year Warranty

ACCESSORIES

RECORDERS

VT-TR4K

Passive Video Balun

Transmitter / Receiver

Pair for HD-TVI / AHD

/ CVI for Distances Up

to 1440’

VT-TR4VPK

Video and Power Balun

Transmitter / Receiver

Pair for HD-TVI / AHD

/ CVI for Distances Up

to 1000’

VT-TJB03A

Optional Junction Box for

Cable Management

VT-TFMT-S

Optional Semi-Flush

Mount

VT-TWMT3

Optional Wall Mount

VT-TPLMT

Universal Pole

Mount Adapter

Ivory, reqs. VT-TJB03A

VT-TCNMT

Universal Corner

Mount Adapter Ivory,

reqs. VT-TJB03A

(888) VITEK-70 | WWW.VITEKCCTV.COM

28492 Constellation Road Valencia, CA 91355
