VITEKCCTV.COM

(888) VITEK-70

VTM-SCT-U4

Four Inch Hand-held 5-in-1 [4K H.265 IP / TVI / CVI / AHD /

CVBS] CCTV Testing Monitor

KEY FEATURES

SPECIFICATIONS

LCD Display4-Inch IPS Touch Screen , 800*480 Resolution

CVBS1 Channel BNC Input, NTSC/PAL (Auto adapt)

PTZ Control, RS485 control, Baud 600-115200bps, compatible

w/ 30+ protocols (PELCO-D/P, Samsung, Panasonic)

IP Test 4K/H.265/H.264IP Discov. / Quick ONVIF / IPC Test / RTSP Play / Client APK

IP Camera Rapid VideoAutomatically View Video, Create Testing Report

Coaxial HD Test8MP [4K] TVI, CVI, AHD 3840 x 2160 (15fps),

Control over COAX, OSD menu

Zoom ImageZoom, Screen Snapshot, Record, Save, View, Record+Playback

Network TestLink Monitor, Port Flashing, Ping Test

Audio Test1 Ch. Audio Signal Input, Test for Sound Function, 1 Ch. Audio

Signal (Headphone Connection)

Data MonitorCaptures / Analyze Command Data from Controlling

Device + Can Send Hexadecimal

Drop-Down Menu

(All Interfaces)

Select PoE Power Switch, IP Setting, CVBS, LAN, Info

Operation Languages

English, Chinese, Korean, Russian, Italian, French, Polish, Spanish, Japanese

Auto-Off1-30 (mins)

BatteryBuilt-in 7.4V Lithium Polymer Battery, 2400mA, 8 hr. Working

Period, 4~5 hr. Charging Period

Power (12V / 3A power)Output DC12V / 3A Power Out: Temporary Power Supply

Power (PoE Output)48V PoE Power Output, Max Power 24W

External Power SupplyDC 12V/1A

Working Temperature14~122F (-10 ~ 50C)

Working Humidity30% - 90% (Recommended)

Dimension / Weight4.96 x 3.27 x 1.3” (126 x 83 x 33mm) / 7lbs (3.2kg)

HD

OVER COAX

APPLICATIONS

The Vitek VTM-SCT-U4 Multi Format Testing Monitor is an

indispensable All-in-One tool for the most demanding CCTV

Installers. The compact 4-inch touch-screen display boasts a high

quality 800 x 480px image, displaying HD Network and COAX-

based cameras in high resolution. This model also supports ONVIF,

PTZ control, Network Cabling Installation, Video Transmission

Channel Testing, and more.

FUNCTIONALITY

• Supports 8MP TVI / CVI / AHD, 4K H.265 IP, CVBS

• H.265/H.264, 4K Video Display via Mainstream

• Compact, 4” Touch Screen

• Portable, Easy-to-Carry-and-Hold Design

• ONVIF Compliant with Other Leading Manufacturers’ IP Cameras

• Rapid ONVIF, Auto View Video + Test Report Creation

• Built in WIFI, Creates WIFI Hotspot & Displays Wireless Camera Images

• Innovative HD-Over-COAX Focus, Video Signal Quality Test

• 10/100/1000M Ethernet, Network State and Traffic Display

• Tester Play: Simultaneous Tester, Android Mobile Phone, PC Display

• One Button IP Discovery: Detects All Network Camera IP Addresses

• One Button Rapid Video: Detects all Network Cameras with Auto Display

• Network Tool: PING Test, IP Address Scan, Port Flashing

• Drop-down Menu Selects: Poe Power, IP Setting, CVBS, LAN Information

• Self-updating Software: Install Apps with Android

• Media player, Supports 4K Video Files and MKV/MP4 Media Files

• Displays IP Cameras’ Genuine Resolution

• PTZ Control Supporting 30+ Protocols (Incl. PELCO-P, PELCO-D, Samsung)

• Audio In, Supports Record / Save Audio

• Features LED Lamp, Calculators, Music Players and Other Application Tools

• 7.4 V / 2400mA Lithium Ion Polymer Battery with 8 hr. Life (4~5 Charging hrs.)

• DC12V / 3A Power Out: Temporary Power Supply

• DC48V PoE Power Output (Max. Power 24W)

• Package Includes: Tester, Adaptor, Battery, Tool Bag, DC12V Power Cable,

BNC Cable, RS485 Cable, Audio Cable

• 3-Year Warranty

(888) VITEK-70 | WWW.VITEKCCTV.COM

28492 Constellation Road Valencia, CA 91355
