TVM 5405/5605 Series - English 1

TVTVM

MM 5

554

440

005

55 S

SSe

eer

rri

iie

ees

TVTVM

MM 5

556

660

005

55 S

SSe

eer

rri

iie

ees

FFu

uull

llll I

IIn

nnsta

sta

stastal

lll

lla

aati

titio

oon

nn Gu

GuGui

iid

dde

Everything you need to get your TV safely on the wall, in no time

BeBefo

fofore

rere y

yyo

oou

uu st

ststar

arart

…we just wanted to say thanks for choosing Vogel’s. Smart choice.

And you’re already making another smart choice – reading the manual! Keep reading to learn all about

safe, efficient installation, and how to use your new mount.

TVM 5405/5605 Series - English 2

StStay

ayay s

ssa

aafe

fefe

Warni

WarniWarning

ngng

Always read these safety instructions carefully before installing and using this product.

Following these instructions is strictly required. Incorrect mounting and/or installation could put

you, your TV, and your family at substantial risk.

Don’t dare risk it… Read all

lVogel’s recommends that the mounting and/or installation of this product should be carried out

by a suitably qualified expert.

lVogel’s cannot be held responsible for any injury and/or damage caused by incorrect

installation.

lPlease consult the manual for your TV and ensure that the weight and size of the TV is within

the maximum weight and size limits specified for this product, and that the TV mounting bolts

used are of a suitable length and diameter. Note that not all the TV mounting accessories

provided are required for the installation of any one TV.

lThe wall mounting accessories provided are exclusively intended for installation on walls made

of solid brick, solid concrete or solid wood columns.

lAny material covering the wall must not exceed 3 mm/ 0.12 inch.

lFor mounting on walls made of other materials, such as hollow bricks, wood panels or

plasterboard, please consult your installer and/or specialist supplier.

lClean the product with a dry, lint-free cloth. Do not use detergents or other solvents to clean the

product.

lOnly qualified, certified personnel may repair the product. Use only original spare parts. The

use of other parts will result in voiding the warranty, and could lead to injuries.

lAlterations to the product and technical modifications are not permitted. This will void the

warranty, and could lead to injuries.

lAlways store the product in a dry and safe place with a temperature between -10°C to +50°C.

lHandle and transport the product with care.

lRepack the product when transporting or not using it for a longer period of time.

lLifting your TV is a two-person job. Don’t be bold!

TVM 5405/5605 Series - English 3

WWha

hahat

tt’

’

’’s

ss in

inin y

yyo

oou

uur

rr b

bbox

oxox?

lSomething missing? Make sure your packaging has everything in place:

A. Wall mount

C. Interface strips

D. Safety instructions

E. Bolts for fastening strips on TV (see contents below)

F. Spacers

G. Washers Ø 18 mm

H. Screws

I. Plugs (fischer© DuoPower)

J. Washers Ø 22 mm

K. Cover

Produktspezifikationen

Marke:	Vogel's
Kategorie:	Nicht kategorisiert
Modell:	TVM 5405
Breite:	493 mm
Produktfarbe:	Schwarz
Höhe:	435 mm
Befestigungstyp:	Wand
Höchstgewichtskapazität:	75 kg
Zertifizierung:	TUV
Menge pro Packung:	1 Paar(e)
Panel-Montage-Schnittstelle:	100 x 100,100 x 200,200 x 100,200 x 200,300 x 200,300 x 300,400 x 200,400 x 300,400 x 400,200 x 300 mm
Schnellinstallationsanleitung:	Ja
Maximale Bildschirmgröße:	77 "
Schrauben enthalten:	Ja
Anzahl der Display unterstützt:	1
Minimum Bildschirmgröße:	32 "
Minimale VESA-Halterung:	100 x 100 mm
Maximale VESA-Halterung:	400 x 400 mm
Abstand zur Wand (max):	15 mm
Abstand zur Wand (min):	15 mm
Verbessertes Kabelmanagement:	Ja
Geeignet für Computermonitor:	Ja
