Seite 1/4
Operator’s Manual
Conveyor Bagel and Bun Toasters
Model JT2B
©
2017 The Vollrath Company L.L.C. Part No. 350803-1 en 8/23/17
Register your product at Vollrath.com/registration and become eligible to win a free 10" Vollrath Tribute® fry pan.
Thank you for purchasing this Vollrath equipment. Before operating the
equipment, read and familiarize yourself with the following operating
and safety instructions. SAVE THESE INSTRUCTIONS FOR FUTURE
REFERENCE. Save the original box and packaging. Use this packaging
to ship the equipment if repairs are needed.
SAFETY PRECAUTIONS
To ensure safe operation, read the following statements and understand
their meaning. This manual contains safety precautions which are
explained below. Please read carefully.
Warning is used to indicate the presence of a hazard that will or can
cause severe personal injury or death.
Caution is used to indicate the presence of a hazard that will or can
cause minor or major personal injury if the caution is ignored.
NOTICE: Notice is used to note information that is important but not
hazard-related.
To reduce risk of injury or damage to the equipment
• Plug only into grounded electrical outlets matching the voltage on
the rating plate.
• Use this equipment in a flat, level position.
• Unplug equipment and let it cool before cleaning or moving.
Equipment remains hot after it is turned off.
• Do not touch during operation. Unplug when not in use.
• Keep equipment and power cord away from open flames, electric
burners or excessive heat.
• Do not operate unattended.
• Closely supervise equipment operating in public areas and/or
around children.
• Do not operate if equipment has been damaged or is malfunctioning
in any way.
FUNCTION AND PURPOSE
This equipment is intended to toast bread products. It is intended for
use in commercial foodservice operations only. It is not intended for
household, industrial or laboratory use.
CLEARANCE AND ENVIRONMENT REQUIREMENTS
Do not place toaster on surfaces or near walls, partitions or kitchen
furniture unless they are made of non-combustible material or clad with
non-combustible heat-insulating material. Toasters must not be used
near or below curtains and other combustible materials.
Do not place the toaster adjacent to a heat producing appliance.
SET UP
1. Place the toaster on a hard, flat, stable surface.
2. Turn the toaster on it’s side with the bottom facing you.
3. Install the feet.
NOTICE: Feet must be installed. Failure to install the feet will
restrict airflow and cause the toaster to overheat.
4. Install the collection pan by placing the back edge of the pan on the
lip at the back of the toaster. Line up the hole in the pan with the
screw. Tighten the screw to secure the collection pan.
WARNING
CAUTION
Item No. Model Description
CT4B-2081200
JT2B
Bagel/bun toaster, 208V, 1200 slices per hour
CT4B-2401200 Bagel/bun toaster, 240V, 1200 slices per hour
2 Conveyor Bagel and Bun Toasters Operator’s Manual – Model JT2B
FEATURES BEFORE FIRST USE
1. Clean the toaster. See “Cleaning” on page 3.
2. Insert the crumb tray. Make sure the feed ramp is placed in the up
position.
OPERATION
NOTICE: The crumb tray must be installed in the toaster during
operation. Failure to install the crumb tray will cause the
toaster to overheat.
Tips
Preheat
1. Plug the toaster into a grounded electrical outlet that matches the
rating on the name plate found on the side of the toaster.
NOTICE: Using a voltage other than the nameplate rated voltage
will cause damage to the unit. Incorrect voltage,
modification to the power cord or electrical components
can damage unit and will void the warranty.
2. Toasters with an adjustable heat shield: Adjust the heat shield so the
tallest bread product can pass below it. Excess space above the
product will create heat loss and may reduce performance.
3. Rotate the power knob to the full power position (I).
4. Set the conveyor speed control knob to 7.
5. Wait 5 minutes for the toaster to preheat.
Test
1. Adjust the settings for the product to be toasted. See the Tips chart
at the top of this page.
2. Test the settings by placing a sample of the bagel or bun to be
toasted onto the feed ramp. Place the bagel or bun with the cut side
facing up.
3. Evaluate the results.
Toast Bagels or Buns
1. Adjust the conveyor speed as needed to achieve desired browning.
• Toast too light: Rotate the speed control knob to a lower number
to reduce the speed and darken the toast.
• Toast too dark: Rotate the speed control knob to a higher number
to increase the speed control and lighten the toast.
2. For best performance do not overload the toaster. Wait a few
seconds before loading a second row of bagels or buns into the
toaster.
If a Bagel or Bun Becomes Stuck
1. Rotate the power knob to the OFF position (O) and unplug the
toaster.
2. Let the toaster cool completely.
3. Use tongs to remove the bagel or bun. Take care to not bump the
glass heating elements above and below the conveyor.
A Conveyor Speed Control Knob
B Power Knob
Full Power - maximum heat
Off
Standby - reduces electrical consumption by 75%.
C Heat Shield - Adjustable on the high-clearance toasters
D Feed Ramp
E Crumb Tray
F Collection Pan
G Reset Button - Reference only. Access is via the front of the
toasters. See page 4.
C
D
E
F
A
B
G
Back View
Front View
CAUTION
Burn Hazard
Do not touch the equipment while it is heating or operating.
Hot surfaces can burn skin.
Bread Product Suggestions
Bagels, wheat or rye bread or
products with high moisture content.
Use a slower conveyor speed.
Buttered or coated, such as pastries Not recommended.
Frozen Must be thawed before toasting.
Conveyor Bagel and Bun Toasters Operator’s Manual – Model JT2B 3
CLEANING
NOTICE: Do not use abrasive materials, scratching cleansers or
scouring pads to clean the exterior of the equipment.
These can damage the finish.
NOTICE: Do not spray the controls or outside of equipment with
liquids or cleaning agents.
Daily Cleaning
1. Rotate the power knob to the OFF position (O) and unplug the
toaster.
2. Let the toaster cool completely.
3. Slightly dampen a soft cloth with warm water.
4. Use the dampened cloth to clean the exterior of the toaster, the air
intake under the toaster, the feed ramp, crumb tray and collection
tray.
5. Press and hold an abrasive pad or brush against the conveyor. Move
the pad or brush back and forth (left to right) across the conveyor to
remove food debris.
PREVENTATIVE MAINTENANCE
Contact an authorized service agent for a professional cleaning of the
components.
WARNING
Electrical Shock Hazard
Do not spray water or cleaning products. Liquid could contact
the electrical components and cause a short circuit or an
electrical shock.
CAUTION
Burn Hazard
Allow equipment to cool before moving or cleaning.
TROUBLESHOOTING
Problem Might be Caused By Course of Action
Toaster does not heat and the
conveyor belt does not move.
Toaster is not plugged in. Plug in the toaster.
Power knob setting is incorrect. Rotate the power knob to full power.
The wall breaker may be tripped. Reset the breaker.
The reset may be tripped. Look under the toaster to see if an object is preventing the fan
blades from turning.
1. Rotate the power knob to the OFF (O) position.
2. Unplug the toaster.
3. Wait 30 minutes for the toaster cool.
4. Remove the object.
5. Plug in the toaster.
6. Rotate the power knob to the ON (|) position.
7. Press the reset button.
8. If the problem persists call Vollrath Technical Services.
