VULCAN-HART COMPANY, P.O. BOX 696, LOUISVILLE, KY 40201-0696, TEL. (502) 778-2791
INSTALLATION , OPERATION
SERVICE & PARTS MANUAL
ES, EL & ET STEAM JACKETED KETTLES
MODELS
ES25 ML-52642
ES30 ML-52643
EL40 ML-52644
ES60 ML-52645
EL80 ML-52646
ET100 ML-52647
ET125 ML-52648
ET150 ML-52649
FORM 30965 Rev. A (06-03)
For additional information on Vulcan-Hart Company or to locate an authorized
parts and service provider in your area, visit our Web site at www.vulcanhart.com
– 2 –
© VULCAN-HART COMPANY, 2003
TABLE OF CONTENTS
GENERAL..............................................................................................................................................................3
INSTALLATION .....................................................................................................................................................3
Unpacking .................................................................................................................................................3
Location ....................................................................................................................................................3
Leveling .................................................................................................................................................... 3
Installation Codes and Standards ...........................................................................................................3
Electrical Connections .............................................................................................................................4
Faucet Connection (Optional) .................................................................................................................4
OPERATION .........................................................................................................................................................5
Before First Use .......................................................................................................................................5
Controls .................................................................................................................................................... 5
Filling the Water Jacket ........................................................................................................................... 6
Using the Kettle ........................................................................................................................................6
Kettle Food Draw-Off Valve .....................................................................................................................6
Cleaning .................................................................................................................................................... 6
MAINTENANCE .................................................................................................................................................... 8
Periodic Maintenance ..............................................................................................................................8
Pressure Relief Valve ...............................................................................................................8
Low Water Cut-Off .................................................................................................................... 8
Sight Glass Assembly ............................................................................................................... 8
Draw-Off Valve ..........................................................................................................................8
Vent ........................................................................................................................................... 8
Kettle Jacket Fluid ....................................................................................................................8
SERVICE ...............................................................................................................................................................9
General Notes ..........................................................................................................................................9
Servicing Procedures ...............................................................................................................................9
Thermostat ................................................................................................................................ 9
Low Water Cut-Off ..................................................................................................................10
Pressure Limit Switch ............................................................................................................. 10
Magnetic Contactor .................................................................................................................10
Electric Heating Elements ......................................................................................................10
Replace On-Off Switch ...........................................................................................................11
Replace Signal Light ...............................................................................................................11
Replace Pressure Gauge .......................................................................................................11
Correct Leaking Draw-Off Valve ............................................................................................11
Service and Parts Information ...............................................................................................................11
PARTS LIST ........................................................................................................................................................ 12
WIRING DIAGRAMS ...........................................................................................................................................14
DIMENSIONS AND SERVICE CONNECTIONS ............................................................................................... 18
– 3 –
Installation, Operation and Care of
MODEL ES, EL & ET STEAM JACKETED KETTLES
KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE
GENERAL
Your Vulcan steam jacketed kettle is produced with quality workmanship and material. Proper
installation, usage and maintenance will result in many years of satisfactory performance.
Vulcan-Hart Company suggests that you thoroughly read this entire manual and carefully follow all of
the instructions provided.
INSTALLATION
Prior to installation verify that the electrical service agrees with the specifications on the machine data
plate located inside the front cover at the lower left.
UNPACKING
This kettle was inspected before leaving the factory. The transportation company assumes full
responsibility for safe delivery upon acceptance of the shipment. Immediately after unpacking, check
for possible shipping damage. If the kettle is found to be damaged, save the packaging material and
contact the carrier within 15 days of delivery.
LOCATION
Position the kettle in its final location. Check that there are sufficient clearances for operating and
servicing the kettle, and for proper clearance of the cover when raised. The kettle draw off faucet should
be located near a floor drain.
LEVELING
Place a spirit level on the rim of the kettle with the cover open. Adjust the feet to level the kettle left-
to-right and front-to-back.
INSTALLATION CODES AND STANDARDS
Vulcan kettles must be installed in accordance with:
In the United States:
1. Local codes.
2. National Electrical Code ANSI/NFPA-70 (latest edition).
