Seite 1/24
©ITW Food Equipment Group, LLC
3600 North Point Blvd.
Baltimore, MD 21222
RETAIN THIS MANUAL FOR FUTURE USE
FORM F- (9- ) 38307 15
INSTALLATION & OPERATION MANUAL FOR
MEDIUM DUTY GAS CHARBROILERS
VCRB47
MODELS
V CRB25
V B36 CR
V B47 CR
WCRB25
W B36 CR
W B47 CR
For additional information on Vulcan or to locate an authorized parts and
service provider in your area, visit our website at www.vulcanequipment.com
- - 2
IMPORTANT FOR YOUR SAFETY
THIS MANUAL HAS BEEN PREPARED FOR PERSONNEL QUALIFIED TO
INSTALL GAS EQUIPMENT, WHO SHOULD PERFORM THE INITIAL FIELD
START-UP AND ADJUSTMENTS OF THE EQUIPMENT COVERED BY THIS
MANUAL.
POST IN A PROMINENT LOCATION THE INSTRUCTIONS TO BE FOLLOWED IN
THE EVENT THE SMELL OF GAS IS DETECTED. THIS INFORMATION CAN BE
OBTAINED FROM THE LOCAL GAS SUPPLIER.
IMPORTANT
IN THE EVENT A GAS ODOR IS DETECTED, SHUT
DOWN UNITS AT MAIN SHUTOFF VALVE AND
CONTACT THE LOCAL GAS COMPANY OR GAS
SUPPLIER FOR SERVICE.
FOR YOUR SAFETY
DO NOT STORE OR USE GASOLINE OR OTHER
FLAMMABLE VAPORS OR LIQUIDS IN THE VICINITY OF
THIS OR ANY OTHER APPLIANCE.
IN THE EVENT OF A POWER FAILURE, DO NOT
ATTEMPT TO OPERATE THIS DEVICE.
Improper installation,
adjustment, alteration, service or maintenance
can cause property damage, injury, or death.
Read the installation, operating and maintenance
instructions thoroughly before installing or
servicing this equipment.
- - 3
INSTALLATION, OPERATION AND CARE OF
MEDIUM DUTY GAS CHARBROILERS
GENERAL
Gas Countertop Charbroilers are des igned for commercial us e only and feature fast,
ef ficient gas heat. Each burner is cont rolled by a n adjustable gas valve. Cast radi ants
ar e located d irectly abo ve each burner to maintain uniform tem perature. Radi ants are
easily removed for cleani ng when cool.
Heavy-duty, cast iron top grates are reversible to al low al l or part of the cooking grid
surface to be level or sloped. Grooves, cast in the top g rates, permit fat runoff and
reduce flaring when tilted towards the f ront. A grease drawer is provided to collect fat
run-of f; it opens to the front for inspection or drain -off .
Model
Number Of Burners
BTU/hr Input Rating
VCRB25 / WCRB25
4
58,000
VCRB36 / WCRB36
6
87,000
VCRB47 / WCRB47
8
116,000
INSTALLATION
UNP ACKING
This charbroiler was inspected before leaving the factory. The carrier assumes full responsibility for the
safe delivery upon acceptance of the shipment. Check for possible shipping damage immediately after
receipt.
If the charbroiler is found to be damaged, complete the following steps:
1. Carrier must be notied within 5 business days of receipt.
2. Carrier’s local terminal must be notified immediately upon discovery (note time, date, and
who was spoken to), and follow up and conrm with written or electronic communication.
3. All original packing materials must be kept for inspection purposes.
4. The charbroiler cannot have been moved, installed, or modied.
5. Notify Vulcan Customer Service immediately at 800- -2028. 814
Caref ully unpack your broiler and make sure that no parts are discarded with char
pack aging material. A pressure regulator designed to operate with the broiler has been
supplied and must be installed before the charbroiler is placed into service (Refer to GAS
PRESSURE REGUL ATOR IN STALLATION in this manual ).
