WAC Lighting retains the right to modify the design of our products at any time as part of the company's continuous improvement program. 1

waclighting.com

Phone (800) 526.2588

Fax (800) 526.2585

Headquarters/Eastern Distribution Center

44 Harbor Park Drive

Port Washington, NY 11050

Central Distribution Center

1600 Distribution Ct

Lithia Springs, GA 30122

Western Distribution Center

1750 Archibald Avenue

Ontario, CA 91760

INSTALLATION INSTRUCTION

I CAN’T BELIEVE IT’S NOT RECESSED

FM-616G2

WARNING

IMPORTANT: NEVER attempt any work without shutting o the electricity.

- Read all instructions before installing.

- System is intended for installation by a qualied electrician in accordance with the National Electrical Code and local regulations.

- Go to the main fuse box, or circuit breaker. Place the main power switch in the “OFF” position and unscrew the fuse(s) or

switch ”OFF” the circuit breaker switch(es) that control the power to the xture or room that you are working on.

- Place the wall switch in the “OFF” position.

- Supply conductors (Power Wires) Connecting the xture must be rated minimum 90°C. If uncertain, consult an electrician.

CAUTIONS

- These luminaires (xtures) are designed to meet the latest NEC requirements and are listed in full compliance with UL 1598.

- Before attempting installation, check your local electrical code, as it sets the wiring standards for your locality.

Fig. 1

Fig. 2

1. Attach two mounting screws into outlet box leaving enough of

screw exposed to engage keyholes in the top of xture (Fig. 1).

Note: Keyhole mounting distance is 3.5” ().Fig. 2

2. Provide electrical service according to the “National Electrical

Code” or your local electrical code to the outlet box.

3. Connect supply wires to xture wires and insulate with proper

wire nuts .

4. Connect incoming ground wire to xture ground wire (green or

bare).

5. Connect incoming common wire to xture common (white).

6. Connect incoming hot wire to xture black wire.

7. Raise the xture to the junction box, guiding screw and tighten

screws through keyhole slots.

8. Snap the keyhole covers into place to hide mounted screws.

LENS INSTALLATION

Secure the lens over the LED module by snapping it into place.

Wire Connector

Qty: 3 pcs

P3

ACCESSORIES BAG (A-FM616):

Junction Box Screw

Qty: 2 pcs

#8-32, * 3/4”

Stainless Steel

Keyhole Cover

Qty: 2 pcs

3/0-4/0, 4/0 or 4” octagonal

junction box, (by others)

Mounting Screw

Ground

Keyholes

Fixture

Keyhole Cover

Dist. Between Keyholes

Lens

3”½

3”

INSTALLATION

Uses 4” junction box or a combination 3/0-4/0 electrical box.
